• Model NO.：ET-360B
• Edging thickness：0.4-3mm
• Automatic Grade：Automatic
• Panel Feeding Speed：15m,min
• Certification：CE, ISO
• Panel Thinkness：10-60mm
• Min.length panel：120mm
• Min.width panel：60mm
• Manufacturing Principles：Glue Tank Underneath
• Customized：Customized
• After-sales Service：Free Accessories
• Product Name：Edge Bander
• PLC System：Delta Brand-Taiwan
• Guide Rail：Hiwin-Taiwan
• Electric Element：Airtac-Taiwan
• Option Fuction：Rough Trimming, Corner Tracking, Scrappin Slotting
• Panelthickness：12-55mm
• Workpiecethickness：10-60mm
• Machine Type：Edge Banding Machine
• Panel Preheating Power：0.3 Kw
• Glue Melting Power：1.5 Kw
• Panel Preheating Motor：0.3 Kw
• End-Trimming Motor Power：0.37 Kw*2
• Rough-Trimming Motor Power：0.75 Kw*2
• Fine-Trimming Motor Power：0.75 Kw*2
• Total Power：12.5 Kw
• Transport Package：Plywood Box with Strength Film
• Specification：4700,925,1560mm
• Trademark：ET
• Origin：China
• HS Code：8465940000
• Production Capacity：1000set,Year
• Package size per unit product：4800.00cm * 1000.00cm * 1600.00cm
• Gross weight per unit product：1400.000kg
• Lead Time：15 days (1 - 1 Pieces) 20 days (2 - 10 Pieces) To be negotiated ( > 10 Pieces)

Product Description

Detailed Photos

ET-60EET-360AET-360BET-360CET-360YCET-360DET-360FMotor power4KW7.4KW9.4KW8.5KW11KW19KW15KWPanel width≥60mmPanel thickness10~60mmEdge band thickness0.4~3.0mmEdge band width12~65mmFeed speed0~13m/minWorking pressure0.7 Mpasize(LxWxL)mm2740*850*14803700*930*16004080*930*1604180*930*16005000*930*16005700*930*16005900*930*1600ET-60Egluing,trimming,scrapping and buffing,also with manual end cuttingET-360Agluing,end cutting,fine trimming,scrapping and buffingET-360Bgluing,end cutting,rough trimming,fine trimming,scrapping and buffingET-360Cgluing,end cutting,fine trimming,scrapping,vertical grooving,horizontal grooving and buffingET-360YCpre-milling,gluing,end cutting,rough trimming,fine trimming,scrapping and buffingET-360Fpre-milling,gluing,end cutting,fine trimming,corner rounding,scrapping, and buffingET-360Dgluing,end cutting,rough trimming,fine trimming,corner rounding,scrapping and buffing

Company Profile

FAQ

Q1: Are you a manufacturer or trading company?
      A: We are a manufacturer since 2003. We are dedicated to woodworking machinery manufacturing.

Q2: Where is the nearest airport and port from your factory?
      A: The nearest airport and port is Qingdao/Jinan international airport.

Q3: How can I get an accurate price?
 Kindly send us the picture of furniture you want to produceand and the working size.
 Or detailed machine functions you need, electricity voltage, Hz.

Q4: How is your after sales service?
Our sales are online for 24-hours. We can also supply overseas install service. Also we have more than 10 countries warehouse and department.

Q5: How long is the delivery time?
 Generally 7 ~ 15 days.

Q6: Can I get a machine according to my own requirements?
Sure.We accept OEM and ODM

Q7: If my machine is broken. Can you repair it for me?
 Yes. Our machine is with top quality, if any problem, We have free traning and conduction online. If there is big trouble within warranty time, we will send you new parts and repair.

Q8: How is the quality of your machine?
Our machine adopts heavy machine body and famous parts such as SKF bearing, Hiwin guide rail, Delta Screen and system, top quality motor etc, well commissioning etc to make sure the whole machine quality is no problem, we have many reputation feedback from Clients.

Q9: What's your MOQ and delivery?
 1 set by LCL. 3~9 sets by container.
