High Speed Remove Knots Automatic Optimizing Length Cross Cut Saw
Shandong STX Machinery Trade Co., Ltd.- Warranty：18 Monthsj[
- Type：Cross Cut Saw
- Power Type：Electric
- Layout：Horizontal
- Controlling Mode：CNC
- Automatic Grade：Automatic
Base Info
- Model NO.：MJD344
- Precision：High Precision
- Certification：CE
- Customized：Customized
- Condition：New
- Color：Customized
- After-sales Service：Online Support
- Cutting Speed：25-35m,Min
- Cutting Thickness：9-75mm
- Mini Material Length：350mm
- Max Cutting Section：75*125mm , 50*180mm
- Max Feeding Speed：100m,Min
- Transport Package：Wood Case
- Trademark：STX
- Origin：China
- HS Code：846591
- Production Capacity：2000 Sets,Year
Description
Model
MJD344
Max feeding speed
100m/min
Efficiency
25-35m/min (Cut 4-5 pieces per minute)
Saw Blade Diameter
450*3.2*30*100T / 500*3.8*30*120T
Max Cutting Section
75*125mm / 50*180mm
Cutting thickness
9-75mm
Mini material length
350mm
Max material length
No limited
Motor rotary speed
4000 r/min
Saw spindle power
5.5kW
Feeding servo motor power
4.5kW*2
Top press roller qty
6
Bottom press roller qty
6
Feeding conveyor width
200mm
Overall diameter
14000*1400*1550mm
Weight
2000kg
