• Model NO.：NM-483
• Spindle：6kw Air Cooling Spindle*3 Sets
• Controller：Nk-105 DSP, Nc Studio
• Table：T-Slot Vacuum Table
• Rail：Taiwan Linear Rail
• Rack：High Helical Racks
• Motor：Servo Motor, Stepper Motor
• Software：Type 3 , Arrcam
• Pump：7.5kw Water Cooling Pump
• Transport Package：Plywood Box
• Specification：1220mm*2440mm
• Trademark：DLM
• Origin：China
• HS Code：84609090
• Production Capacity：600 Sets,Year

Model

NM-483 (Asynchronous Type)

X-Y-Z axis working area

1,300 x 2,500 x 200mm

Machine size

3100 x 2200 x 1750mm

Resolutions

0.025mm

X-Y movement

Rack and pinion, gear drive/Taiwan

Z movement

Ball screw drive

Guide

Linear 25 square/Taiwan

Max. speed

35,000mm/min

Max. cutting speed

25,000mm/min

Spindle 1-3

6kw (Chinese Fan cooling)

Spindle 1-3

18,000rpm

Inverter power

7.5kw

Drive motors

stepper / servo

Working voltage

AC380V/50-60Hz, 3-phase

Command code

G code

Computer interface

USB 2.2

Collet

ER25- 3.175mm, 6mm, 12.7mm

Software

Type3 Software/France

Controls

DSP A15 For Two Spindle

Packing dimensions

3220 x 2280 x 1870mm,1300 kgs

Standard equipment included

1. Auto tool surface sensor

2. Manual oil lubrication system

3. Dust hood

4. T-slot table with mechanical clamps
