Wood Cold Press Machine for Wooden Doors
QINGDAO SOSN MACHINERY CO., LTD.- Warranty：1 Year Warranty
- Work Forms：Hydraulic Pressure
- Processing Technics：Cold Press
- Structure：Frame Type
- Pressing Shape：Flat Press
- Platen Surface Pressure：Low Pressure
Base Info
- Model NO.：MYJ100T
- Pressing Layer：Single Layer
- Work Mode：Period
- Controlling Mode：Artificial
- Automatic Grade：Semiautomatic
- Certification：CE, ISO
- After-sales Service：1 Year Warranty
- Name：Cold Press Machine
- Size of Worktable：1250*2500 mm
- Max. Pressure：100t
- Max. Platen Pressing：1000 mm
- Hydraulic Pump Power：5.5 Kw
- Transport Package：Simplified Package
- Specification：2860*1250*3400 mm
- Trademark：SOSN
- Origin：China
- Production Capacity：300 Sets,Month
Description
Basic Info.
Model NO. MYJ100T Pressing Layer Single Layer Work Mode Period Controlling Mode Artificial Automatic Grade Semiautomatic Certification CE, ISO After-sales Service 1 Year Warranty Name Cold Press Machine Size of Worktable 1250*2500 mm Max. Pressure 100t Max. Platen Pressing 1000 mm Hydraulic Pump Power 5.5 Kw Transport Package Simplified Package Specification 2860*1250*3400 mm Trademark SOSN Origin China Production Capacity 300 Sets/MonthProduct Description
Wood Cold Press Machine for Wooden Doors
| model | MYJ100T |
| Size of worktable (mm) | 1250x2500mm |
| Nominal pressure | 100T |
| Max. Platen Pressing | 1000mm |
| Working speed | 180mm/min |
| Hydraulic pump power | 5.5 kw |
| Dimensions of machine | 2860x1300x3400 |
Machine features:
1. Timing control, adjustable pressing time according to processing requirements
2. High pressing speed up to 1.0m/min
3. Steel welded frame with high precision and compact structure
4. High operation safety without operating risks
5. Other pressure tonnage 60 ton, 80 ton, 100 ton are available for making
Have any need, pls feel free to contact us
