Double-Roller CNC Integrated Wood Veneer Peeling Machine Peeler

Linyi Gaotong Import & Export Co., Ltd.
  • After-sales Service：Online Technical Support
  • Warranty：1 Year
  • Type：Peeling Machine
  • Automatic：Automatic
  • Certification：CE
  • Name：Wood Veneer Peeling Machine

Base Info

  • Model NO.：GTPM001
  • Roller Size：1500mm
  • Max Processing Log Diameter：550mm
  • Minim Log Diameter：32
  • Other Size：Available
  • Project Solution Capacity：Cross Categories Consolidation
  • After Sale Service：Online Technical Support
  • on-Site Installation：Available
  • Color：Customziable
  • Spare Parts：Available
  • transportation：by Sea
  • Loading：by Container
  • Transport Package：Loosing Packing
  • Specification：1500mm
  • Trademark：GTCO
  • Origin：China
  • HS Code：8465
  • Production Capacity：2,Day

Description

Double-roller CNC Integrated Wood Veneer Peeling machineRoller Length1500mmMax Processing Log DiameterΦ550Min Residual wood Diameter(mm) Φ32Single and double roll diameter(mm)Single rollerΦ100 , Double RollerΦ125Working thickness Range(mm) 1.0mm to 4.0mmPeeler Blade size (mm)  150*160*13Main Line Speed (m/min)0-80m/min and adjustableTotal Motor Power(kw)
(45.4KW )Single Roller : R87 reducer ,7.5KW*2KW
Double Roller : R87 reudcer,7.5KW*2KW
Feeding  motor:  R87 reducer, 11KW;
Blade  motor:    2.2KW.
Conveyor Motor:  2.2KWOverall Size(L*W*H) mm4500* 2250*1450mmWeight (KGS)About 6800KG
