• Rotation of Spindle：± 90°
• Xyz Structure：Xy- Gear Rack , Z-Ball Screw
• Operating System：DSP,Lnc,Syntec
• Max Working Speed：20000mm,Min
• Transport Package：Wooden Box
• Specification：4000*2280*2000mm
• Trademark：IGOLDENCNC
• Origin：Jinan, China
• HS Code：8465990000
• Production Capacity：80 Sets,Month

Model

1530 atc wood router

Spindle

6kw / 9kw air cooling spindle

Working table

Vacuum & T-slot table

Transmission mode

Z axis Taiwan TBI screw

Dynamic system

Servo motor

Inverter

Fuling/Delta Brand

Control system

DSP/Taiwan LNC/Syntec

Filter

Prevent electromagnetic interference

Working area

1500*3000*500mm

Max working speed

25m/min

Max velocity

50m/min

Spindle speed

0-24000rmp

Working voltage

AC220/380V

Interface

USB

Command language

G code

Software environment

Type3/Artcut/Artcam/Ucancam

Running environment

Temperature:0-45°C

       1. Do you offer training about products?

Yes, we can assign technician arrive at your company for the training at some charge, and accommodation, food, tickets will be charged.

        2. Are there any machine in my area I can observe?

Igoldencnc have machines at many countries, if there is our machine in your country, we can contact the customer to arrange a visit for you.

        3. How do you make the machine to cut parts? Is it easy?

CNC Controller, the motion control software we use, is based on standard G-codes. The G-codes provide a source code comprised of inches and axis movements which can be edited and understood by others. Most CAM packages will generate G-codes from the drawings you create. What you need is to create program from CAM software.

        4. I am new to CNC, how difficult are your machines to operate?

We help a lot of beginners in CNC, if you have a reasonable knowledge of computers and are willing to spend a little time learning it is not that bad. Quite often when we sell a machine we send the manual and CD's out before the machine is ready for the customer to read ahead.

         5. I want a size that you don`t make as standard, is this possible?

Absolutely, we design and manufacture everything ourselves and indeed do many custom builds, see custom made cnc router.

         6. How do you send your CNC wood router?

They are firstly greased thouroughly and packaged in a free-fumigation wooden crate. At OMNI™ we strive to make your buying experience as convenient as possible. We work directly with shipping companies to ensure the best price for the shipment and we pass those savings on to you. Please notify salesperson at the time of your quote request if you wish to arrange for your own shipping method.

Usually, we send machine by ship, sometimes, as customer's requirement, send by air or by train. When the goods arrive at your sea port or destination, you can pick up goods with the bill of lading we offered. Or we can arrange the cargo agent to send goods to your door.

Under FOB/CIF term, you could assign your own cargo agent to clear customs and pick up goods at sea port warehouse, under DDP/DDU term, we could arrange goods at your door. Please notice that the truck drivers are not required to assist you with unloading the machinery.

It's your responsibility to move it into your shop. In most cases a forklift will be required.
