Solid Wood Automatic Planer Four Side Moulder Machine
Qingdao Haozhonghao Woodworking Machinery Co., Ltd.- Type：Four-Side Planer
- Working Depth：100-200mm
- Working Width：20-210
- Drivetrain：Feed Drivetrain
- Enter Method：Pushing
- Motor Power：＞10Kw
Base Info
- Model NO.：HJD-M621D
- Cutter Shaft：6
- Spindle Speed：＞5000rpm
- Process Type：Heavy Processing
- Certification：ISO
- Color：White Four Side Planer Machine
- Transport Package：Plastic Bags
- Specification：4560*1725x1735mm
- Origin：Qingdao China
- Production Capacity：5 Sets,Month
Description
OthersFeeding roller diameter Φ140mm Dust pipe diameter Φ140mm Dimension 4560*1725x1735mm Weight 3240kg
Each spindle is driven by an independent motor, and the cutting force is quite strong;
All spindles are arranged in the front, and it is convenient to operate;
Made of ultrahard mold steel, the worktable is durable;
The whole hard worktable is convenient to maintain;
A short material auxiliary device is equipped, so that the short materials can be smoothly charged;
Lower active rollers improve the feeding effect;
Internationally famous electric elements ensure high stability;
A fully closed safety protective shield helps to avoid wood dust flying and isolate noise, and has a safety protection effect;
Pneumatic pressing type feeding wheels are arranged, and the pressing force can be adjusted in segments, so that wood of different thicknesses can be smoothly fed;
Each spindle is driven by an independent motor, and the cutting force is quite strong;
All spindles are arranged in the front, and it is convenient to operate;
Made of ultrahard mold steel, the worktable is durable;
The whole hard worktable is convenient to maintain;
A short material auxiliary device is equipped, so that the short materials can be smoothly charged;
Lower active rollers improve the feeding effect;
Internationally famous electric elements ensure high stability;
A fully closed safety protective shield helps to avoid wood dust flying and isolate noise, and has a safety protection effect;
Pneumatic pressing type feeding wheels are arranged, and the pressing force can be adjusted in segments, so that wood of different thicknesses can be smoothly fed;
