• Model NO.：BY214x8,12(3)H1RC
• Pressing Layer：Multi Layer
• Work Mode：Continuous
• Controlling Mode：PLC Auto
• Automatic Grade：Automatic
• After-sales Service：Free Service on Internet
• Working Layers：3
• Platen Number：4
• Power：52.75kw
• Condiation：Brand New
• Voltage：380V, 50Hz or Customized
• Rated Pressure：120t
• Specific Pressure：3.7kgf,M2
• Heating Method：Electrical Heating
• Heating Power：48kw
• Container：20′gp
• Transport Package：PE Film
• Specification：2500x1300mm
• Trademark：CHANCSMAC
• Origin：China
• HS Code：8465990000
• Production Capacity：30 Sets, Month

Basic Info.

Model NO. BY214x8/12(3)H1RC Pressing Layer Multi Layer Work Mode Continuous Controlling Mode PLC Auto Automatic Grade Automatic After-sales Service Free Service on Internet Working Layers 3 Platen Number 4 Power 52.75kw Condiation Brand New Voltage 380V, 50Hz or Customized Rated Pressure 120t Specific Pressure 3.7kgf/M2 Heating Method Electrical Heating Heating Power 48kw Container 20′gp Transport Package PE Film Specification 2500x1300mm Trademark CHANCSMAC Origin China HS Code 8465990000 Production Capacity 30 Sets/ Month

Product Description

120T Laminating hot press machine
 120T hot press machine is also called hot laminating press, laminating hot press. It is suitable for the furniture factory or panel decorative plant, which can make lamination for panel, such as wooden door, core board, MDF, plywood, chipboard with all kinds of decorative paper HPL or veneer. It can also be sued for drying or leveling veneer.


Product name	LAMINATING HOT PRESS MACHINE
Model	BY214×8/12(3)H1RC
Total pressure	1200KN
Working layer	3
Platen No.& Size	4-2500x1300x42mm(Covered with Mylar)
Platen opening	120mm
Cylinder No.& Dia	8 pieces x φ85mm
Max temperature	120ºC
Heating way	Electric heating with thermic oil
Heating medium:	Thermic oil
Installation power	4+0.75+48KW
Platen opening way	Automatically
Closing speed	30mm/s
Loading way	Length side, Manually
Voltage	3 Phase, 380V, 50Hz, or customized
Packing	Bare but properly secured
Gross Weight	About 7500.00 kg
Container need	1X20'GP

List some questions customers care about, if you have more quotations, please feel free to contact with us1.  Q:What's the mininum order quantity (MOQ)?      R:  One set will be ok.2.  Q: Provide customized machine Yes or NO?     R: Yes. We have professional designers and engineers to supply customized machines. 3.  Q: What is payment terms?     R: 30%T/T in advance, the balance paid before shipment after inspection.
4.  Q: What is the warranty time?
     R: One year.
5.  Q: Overseas engineers avaliable or not?
     R: We can send engineer to overseas to help customer install machine and train worker
