• Model NO.：ZMGB1014
• Working Way：CNC
• Working Size：1000*1400mm
• Oil Pump Power：5.5kw
• Upper Pressure：12t*6PCS
• Side Pressure：7.5t*10PCS
• High Frequency Power：20kw
• Working Thickness：10-130mm
• Weight：3700kg
• Color：as Required
• Service：All Life
• Heating Way：High Frequency
• Package：Wooden Case
• Transport Package：Wooden Case
• Specification：6000*1200*1600mm
• Trademark：HiWinstar
• Origin：China
• Production Capacity：100set,Month

working size1000*1400mmoil pump power5.5kwupper pressure12T*6pcsside pressure7.5T*10pcshigh frequency power20kwworking thickness10-130mmweight3700kgoverall size4100*2420*2150mm



Features

1. Introduction.
High-frequency edge glued panel press is advanced technology for panel making. HF generator generates electromagnetic fields between two electrodes through three-phase alternating current. In this field, glue molecules are polarized - rotated - heated by friction.  High-frequency heating is not like conductive heating, which heats material step by step, but help object heated themselves by friction. This is called high-frequency dielectric heating-quickly, efficiently and evenly. So High-frequency edge glued panel joining press only heat glue line but not the whole panel, saving much power and time, improving the efficiency a lot. Tons of vertical pressure assure flatness of panel, even can correct the curved panel slightly. The machine can help the customer save a lot of wood material for next sanding procession.

2. Features:
1. Main components of equipment:
Control system components mainly apply Taiwan, Japan, USA brand
Touch screen is full touch, PLC module, limit switch, rely are Omron brand. Contractor, lights, button is Eaton brand.
2. Heavy duty design on machine structure by advanced 3D software to make sure long term running, more durable
3. Conveyor belt design, can meet different length of panel making. And heavy duty top pressure can guarantee flatness of panel, which can help customer save wood material.
4. Use special design on control system and apply high capacity of control components to meet tropical region and long term running such as Indonesia, Vietnam, Malaysia, Philippine etc
5. Machine equips Taiwan advanced hydraulic variable pump to meet different dimension and density wood panel. And because of unique design, can make sure oil working in low
temperature, saving power and running more durable for hydraulic system
6. Machine top table equips anti-stick material. Easy to clean the glue.
7. Years' experience on high frequency heating, safety design, high efficiency output, can help customer save more power and workers. Whole system is humanistic


Packaging & Shipping


Company Information


FAQ
1,Can you offer good price with fine quality also?

Surely,if without quality,we cannot win long market.we will loose long-terms customers.Quality is our responsibility.we must produce and test machine well.Becasue we are always expecing long term business.Regarding the price.
we are not sure if it is lowest or highest,But we will be offering reasonble.We don't want heavy profits,we want a acceptable price to you,and we are expecting a bigger quantities of sales for different wood machines.

2,We will be protetcted if we are paying for orders?

Surely yes,we have been exported 1000000$ different wood machine every year,We received the payment,we should produce for you and ship to you without delay. It is honesty and reputy.We could understand that you paid,you want to see machines soon and use soon. and these years alibaba trade assurance you could rely on,you will be protected very well.


3,What's your warranty? can you do more service for us? we wish woud be protected after purchasing machine.

We are pleased to give life continious aftersales service. within 12 months, if spareparts broken,we will send you new for change. we would like to help to solve any troubles when you use machine at any time.and don't be worried,we will keep opening 24 hours for all customers problem or difficilaty. we must help to make solutions within 48 hours.

4,What's your production time? we want faster shipping time also.

Mostly machine we have in stock, some machine we produce need about 7-10days. make fast shipment always. shipping time depends on shipping company.
