Woodworking Machinery

Alumnium Brass Metal Wood Mini Desktop CNC Router

Jinan Chanke Mechanical Equipment Co., Ltd.
  • Type:Engraving Router
  • Spindle Layout:Spindle Over
  • Spindle Number:Single-Spindle
  • Feed Mode:Manual
  • Controlling Mode:CNC
  • Certification:CE, ISO

Base Info

  • Model NO.:ck300
  • Customized:Customized
  • Condition:New
  • Color:Red
  • Working Size:300X300mm
  • Machine Colour:Red or as Your Choice
  • Water Cooling Spindle Power:1.5kw
  • Rotary or Not:It Can But as Custom′s Choice
  • Motor:Stepper Motor
  • Compatible CAD/Cam Softwares:Type3 , Artcam ,
  • Working Voltage:AC220V50Hz or as Your Local Coltage
  • Work off-Line:off Line Working DSP
  • Accessories:Collets, >20 Cutterser25
  • Lathe Bed:Steel Lathe Bed
  • Transport Package:Plywood Packing
  • Specification:iso ,SGS,FDA,CE
  • Trademark:chanke
  • Origin:Shandong
  • HS Code:847989999
  • Production Capacity:50sets,Months

Description


1Machine bodyWhole cast iron2Work dimensions300 x 300 x 45mm3Body dimensions600 x 600 x 600mm
4
Z-axis working area45mm5Max. Feeding height60mm or bigger6Cut thickness of material<20mm7Max.Speed4, 200mm/min8Working speed0 - 3, 000mm/min9Mechanical precision0.01mm10SoftwareType 3 software, Artcut software, Artcam software11Max. Power consumption900W12Power supplyAC 220/50Hz for your need13Driver typeStepper motor14Memory1MB15Spindle1.5KW variable speed, water cooled motor16Spindle speed0 - 24, 000rpm17Blade diameter1 - 6m18Control systemArtcut or Wei hong  (NCSTUDIO) or DSP (USB interface)19CommandG code, u00, mmg, plt20InterfaceRS23221English LCDyes22Running circumstance temperature0 - 45 °c23Relative humidity30% - 75%
 6. Packing of Machine
Water-proof plastic film package with foam protection in each corner.
Solid Seaworthy Wood Box Package with Steel Belt.
Save space as much as possible for container loading.
