500kg 1000kg 2000kg Biomass Energy Plant Wood Pellet Mill Plant for Sale
Zhengzhou AG Machinery & Equipment Co., Ltd.- Type：Vertical Ring Die
- Voltage：380V
- Automatic Grade：Automatic
- Controlling Mode：CNC
- Energy Saving：Energy Saving
- Certification：CE
Base Info
- Model NO.：AG
- Warranty：2 Years
- Customized：Customized
- Condition：New
- Color：Multi Color
- Output：1000 Ton Per Hour
- Motor：55 Kw
- Pellet Size：6mm 8mm 10mm 12mm
- Power Supply：380V; 50Hz
- Rollers：3PCS
- Keyword 1：Wood Pellet Line
- Keyword 2：Wood Pellet Production Line
- Keyword 3：Wood Pellet Plant
- Keywords 4：Biomass Pellet Pant
- Keywords 5：Sawdust Pellet Production Line
- Transport Package：Wooden Case
- Specification：1* 0.45* 0.8 m
- Trademark：AGII
- Origin：China
- HS Code：8474802000
- Production Capacity：20 Units Per Month
Description
(set)
frequency motor with reducer
1.5kw airlock, Cyclone separator and furnace.
Reduce the moisture from 35% to 10-15%
frequency motor with reducer.
Feeding silo with screw feeder and adjusting speed motor
Details of Biomass Wood Pellet Line:
(1) Crushing System
When the thickness of raw wood material is >10mm, and >50 * 50mm(L * W), we need use the Wood Chipper to chip them into small pieces, then crush the small pieces into wood powder with diameter less 3mm by Hammer Mill (Crusher)
(2) Drying System
The best moisture content to pelletizing is about 13-15%. Our Rotary Dryer is made up of Stove and Main Rotary Dryer, which can realize to reduce the moisture from 60% to 10%. Our stove is fueled by coal, which can save electricity consumption largely.
(3) Pelleting System
Driven with heavy- duty gearbox construction can produce continuously in most adverse condition. The imported key elements are of high performance with long life and low maintenance cost. The key parts are made of alloy steel to be very strong and malleable. Die is made of stainless steel. Pellet machine is widely used in the granulation of wood, straw and other biomass sources.
(4) Cooling /sieving /Bagging system
After the pelletizing process, the temperature of the wood pellet is about 60-80 degree, and the moisture content of the wood pellet is about 15%, so we need use Cooler to reduce about 3-4% moisture, such this the wood pellet is easy to store.
(5) Packaging system
After cooling, the wood pellet will not directly enter into the fuel process, avoiding the wood pellet affected with damp. The packing process is necessary. In this process, we assemble our domestic best Semi-Auto Packing Machine to you.
Advantages of wood pellet line:
1. Environmental Friendly.
2. Easy to store and transport.
3. Wide application and good market.
4. Effective. Wood pellets generate high heat output.
5. The raw materials are available locally, sustainable and renewable.
Application of biomass pellet plant:
1. Widely used in households, farming and industries.
2. Mainly suitable for producing feed pellets, fuel pellets, fertilizer pellets,etc.
3. Applied to different grains such as corn, wheat, sorghum, and any type of agro-forestry waste: crops straw, husks, vines, wood chips, etc. (Energy-saving & Environment-protecting)
4. Size range of making wood pellets: Φ3, Φ4, Φ5, Φ6, Φ8, Φ10, Φ12mm
Process of Wood Pellet Production Line:
1. Wood Crusher ( crush the big wood into small pieces like sawdust)
2. Dryer (dry the raw material to proper moisture before making pellets)
3. Pellet Machine ( press raw material into pellets)
4. Cooler ( cool down pellets and remove some moisture)
5. Sieve (remove dust, and broken pellets)
6. Packaging machine (pack pellets into bags of required weight)
Please provide information of your requirements:
1. What is your raw material and size?
2. What is the raw material moisture content?
3. What is the capacity do you need?
4. Do you need automatic system or manual packing?
