Jinan 3 Axis Pneumatic Spindles Atc CNC Machine Routers

Shandong Lintianzhiyuan CNC Equipment Co., Ltd.
  • Condition：New
  • Certification：ISO, CE
  • CNC or Not：CNC
  • Voltage：220V
  • Working Area：1300(X)*2500(Y)
  • Machine Structure：8mm Thickness Welded Steel Tube, Cast Iron Vertica

Base Info

  • Model NO.：LT-1325
  • Spindle Rotating Speed：0-18000rpm
  • Table Surface：Vacuum Table with 5.5kw Vacuum Pump
  • Invert：Fuling Invert
  • Spindle：3.5kw Air Cooling Spindle*3
  • Collect Size：Er20
  • Working Voltage：AC220V,380V, 3 Phase
  • Control System：Nsctudio 95A-3L
  • Guide Rail：Hiwin Linear Square Guide Rail
  • Driving Method：X,Y Axis by Helicia Gear Rack, Z Axis by Pneumatic
  • Motors and Drivers：Stepper Motors 86byg-450b and Leadshine Drivers
  • Transport Package：Plywood Case with Water-Proof Materials
  • Specification：330*195*195cm
  • Trademark：LINTCNC
  • Origin：China
  • HS Code：8465990000
  • Production Capacity：50 Sets

Description

ModelLT-1325 Wood cnc routerWorking area1300*2500Machine structure8mm thickness welded steel tube,cast iron vertical shafts and steel gantryTable surfaceVacuum table with 5.5kw vacuum pumpSpindle3.5kw air cooling spindle*4Spindle rotating speed0-18000rpmCollect sizeER20Guide railHiwin linear square guide railDriving methodX,Y axis by helicia gear rack,Z axis by pneumaticMotors and driversStepper motors and leadshine driversControl systemNcstudio 95a-3lInvertFuling invertMax.idling speed25m/minMax.working speed12m/minWorking accuracy<0.05/300MM Instruction formateG code *.u00*.mmg*.plt  Working voltageAC220V/380V,3Phase  Compatible softwareTYPE3/Castmate/coreldraw/autocad etc  Control cabinetIndependent  OtherTool sensor,oiling system,water pump,dust collector,tool box etc

Application:



Furniture Decoration industry:A large area flat plate engraving, wood, panel furniture carving, wood art murals, wood cabinet doors carving.

Wood Products Processing: Sewing machine table,electrical counter table, sports equipment.
Artwork : Photo Frame, jewelry box.

Musical instrument industry: instrument three-dimensional surface engraving, shape cutting.

Jinan 3 Axis Pneumatic Spindles Atc CNC Machine Routers
After-sale service
1.Two years quality guaranty for the machine and online service everyday day, free technical support.
2.Free training to guarantee you can operate machine correctly.
3.We will provide the consumable parts at an agency price when you need replacement.
4.Our staff can be sent to your company to install or adjust if necessary.
5.The processing demo video and E-catalogue will be mailed as your request.
Technical service
1. Professional technical suggestion before you order a machine.
2. Professional instruction for the operation of machine
3. Compleed machine manual and CD will be provided together with machine.
4. Machine has been adjusted before delivery.
5. 24-hour technical support by email or calling.
6. Machine can e shipped to port within 7 working days after receiving payment.
Jinan 3 Axis Pneumatic Spindles Atc CNC Machine Routers
About company
Jinan 3 Axis Pneumatic Spindles Atc CNC Machine Routers
Jinan 3 Axis Pneumatic Spindles Atc CNC Machine Routers

Any questions feel free contact with me
