Wood Corner Jointing Machine with High Frequency Heating
Shijiazhuang Chancsmac Machine Technology Co., Ltd.- Warranty：One Year
- Work Forms：Hot Pressing
- Processing Technics：Hot Press
- Structure：Frame Type
- Pressing Shape：Flat Press
- Platen Surface Pressure：High Pressure
Base Info
- Pressing Layer：Single Layer
- Work Mode：Period
- Controlling Mode：CNC
- Automatic Grade：Automatic
- After-sales Service：Free Service on Internet
- Transport Package：PE Film
- Specification：800x1200x1250mm; 1150x1200x1250mm
- Trademark：Chancsmac
- Origin：China
- Production Capacity：15 Sets ,Month
Description
Basic Info.
Pressing Layer Single Layer Work Mode Period Controlling Mode CNC Automatic Grade Automatic After-sales Service Free Service on Internet Transport Package PE Film Specification 800x1200x1250mm; 1150x1200x1250mm Trademark Chancsmac Origin China Production Capacity 15 Sets /MonthProduct Description
Introduction:
Wood corner joining machine is also named HF corner jointer, high frequency corning jointing machine. It is applied high frequency dielectric heating technology, which only heats the glue line, safely and efficiently. Different angle of wooden frame/MDF frame, PVC wrapped, paper wrapped frame and painted frame can be assembled 5-10 seconds, which can help customer improve the efficiency and save labor costs. It does not need nail. Can make sure the good looking of frame. Widely used for photo frame, mirror frame, cabinet door, and closet door assembly.
Features:
- Free adjustment working table can meet different angle frame corner joining
- PLC control the whole process automatically. Convenient and easy to operate
- International electric components, stable and durable
- Humanization design on foot pad control: One more choice besides PLC auto control. When join long and big frame, can set hands free to hold the frame.
| Model | HFCJ-13-CH | HFCJ-13-S-CH |
| Voltage | Single phase AC 220V 50Hz | Single phase AC 220V 50Hz |
| Power | 3-5KW | 3-5KW |
| Heating time | 5-10 seconds | 5-10 seconds |
| Frequency | 13.56MHz | 13.56MHz |
| Stapler function | Not including | Including |
| Overall size | 800x1200x1250mm | 1150x1200x1250mm |
| Total weight | 200kg | 250kg |
This type can do both types of jobs: Stapler on the left side. Or apply high frequency heating on the right side.Customer can select the machine working type according to production technology.
