CNC 1325 Main Door Wood Carving Design Machine
Jinan Dwin Technology Co., Ltd.- Type：Engraving Router
- Spindle Layout：Vertical
- Spindle Number：Single-Spindle
- Feed Mode：Manual
- Controlling Mode：CNC
- Certification：CE
Base Info
- Model NO.：dw1325
- Customized：Customized
- Condition：New
- Color：Customized
- Machine Type：Woodworking CNC Router
- Spindle Power：3kw,4.5kw,5.5kw
- Rail：Hiwin Square Rail
- Working Area：1300X2500X200mm
- Table：Vacuum Table
- Cooling System：Watercooling,Aircooling
- transmission：Ball Screw
- Control System：Nc Studio ,DSP
- Software：Types3
- Warranty：18 Months
- Transport Package：Plywood Box, Free of Fumigation
- Specification：1300x2500mm
- Trademark：DWIN
- Origin：Jinan City Shandong Province China
- HS Code：8465990000
- Production Capacity：50set,Month
Description
Type
Woodworking cnc router
Model
DW-1325 cnc router
Working area
1325X2500mm
Table size
1440X3000mm
Table structure
T-slot table (vacuum optional)
Working accuracy
0.05mm
Repositioning accuracy
0.05mm
Transmission
X and Y by rack and pinion, and Z by screw
Max. No-load speed
17m/min
Max. Working speed
12m/min
Spindle power
3.0KW/4.5KW/5.5KW
Spindle speed
0-24000RPM
Power supply
AC220V/50-60Hz
Command
G code/mmg/plt/
Controlling system
Syntec system/ DSP
Dimension
1700*3100*1500mm
Total weight
Approx. 2000kg
Warranty :
1) Guarantee for 18 months
2) Free training to make sure you master the operating of cnc router (on internet or by
telephone)
3) 24-hour technical supporton Internet or by Telephone, free instructions and problem
solving
4) Video CD for machine using and maintaining
