• Model NO.：DW1530
• Machine Structure：Customize Accepted
• Machine Body：Cast Steel
• Table：T-Slot or Vacuum Table or Both
• Machine Transmission System：Can Be Customized According to Your Need
• OEM Service：Accepted
• Control Optional System：DSP
• Z Axis Height Optional：200mm
• Type：Engraving Router
• Spindle Layout：Vertical
• Spindle Number：Single-Spindle
• Feed Mode：Manual
• Controlling Mode：CNC
• Customized：Customized
• Color：Customized
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE
• Trademark：dwin made in china
• Origin：Jinan, Shandong, China
• HS Code：846599
• Production Capacity：50 Sets Per Month

NO.DescriptionParameter
1
X,Y,Z Working Area
1200x2400x200mm
3
X,Y,Z Traveling Positioning Accuracy
±0.03/300mm
4
X,Y,Z Repositioning Positioning Accuracy
±0.05mm
5
Lathe Structure
Welded Structure
6
X, Y Structure
Gear Wheel Transmission, Shaft Linear Bearings
7
Z Structure
Ball Screw, Shaft Linear Bearings
8
Max. Consume power
3.5Kw
9
Max. Speed
0-32000mm/min
10
Max. Working Speed
0-20000mm/min
11
Spindle Power Motor
2.2KW/3.0kw water-coolant Spindle
12
Spindle Speed
0-24000RPM
13
Drive Mode
Stepper Motor
14
Working Voltage
AC220V/380V, 50/60Hz
15
Command
G Code, *uoo, *mmg, *plt
16
Operating System
DSP System (Option: Mach3 PC Software)
17
Interface
USB
18
Flash Memory
128M
19
Collet
ER20
20
X,Y Working Delicacy
<0.01mm
21
Software
Type3,  Ucancam,  Artcam
22
Running Circumstance
Temperature: 0°C~45°C  Relative humidity: 30%~75%
23
Packing Size
Separated: 3200X1950X1404mmIntegrated: 3200X1950X1950mm
24
Gross Weight
900KG

Aftersale Service :
1. One year quality guaranty, the machine with main parts (excluding the consumables
)shall be changed free of charge if there is any problem during the warranty period.

2. Lifetime maintenance free of charge.

3.  Free training course at our plant.

4.We will provide the consumable parts at an agency price when you need replacement.

5.18 hours on line service each day, free technical support.

Machine has been adjusted before delivery.
We provide English operation manual and video to help you to learn the machine.

We are a manufacturer of all kinds of CNC machines, like CNC Wood engravers, CNC Stone engravers and CNC Plasma cutting with well-equipped testing equipment and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in advertisement industry and other industries.
