• Model NO.：GD-1325
• Positioning Accuracy：0.05mm
• No. of Spindles：Multi
• Travel (Y Axis)(mm)：2500mm
• Travel (X Axis)(mm)：1300mm
• Key Selling Points：Multifunctional
• Spindle Motor Power：3.2kw
• Relative Humidity：30%-75%
• Running Temperature：0-45ºC
• Control System：Nc Studio , DSP(Optional)
• Packing Size：3.2*2*1.7m
• Weight：1000kg
• Transport Packages：Plywood Packing
• Color：Customer Needing
• Transport Package：Wooden Case
• Specification：3200*2400*1850mm
• Trademark：Guandiao
• Origin：China Jinan
• HS Code：8465990000
• Production Capacity：50000pieces,Years

ModelMulti process wood cnc routerX,Y,Z Working Area1300x2500x200mmX,Y,Z Traveling Positioning Accuracy<0.03/300mmTable Size1300×3000mmTable Surfacevacuum adsorbed tableFrameHeavy welded Steel StructureSpindle3.5/4.5/6/7.5kw air/water coolingSpindle SpeedAdjustable 0-18,000 rpmDrive Motorsservo motor or stepper motorsInverterFULINGCommandG codeControllerShanLong 1000Working VoltageAC380V/50/ (Option: 220V))Software CompatibilityType3/ArtcamDust collector3.0kw vacuum cleanerVacuum pump7.5kw water-cooled vacuum pumpX, Y StructureRack and Pinion Drive, Taiwan CSK linear guideZ StructureTaiwan Hinwin linear guideMax. Rapid Travel Rate50000mm/minMax. Working Speed25000mm/min

Application


1.Woodworking& furniture decoration field:
wood and compound door, cupboard door, large plate planar engraving, wood carving patterns, panel furniture, red wood furniture engraving.
2. Art work field:
watch& clock frame, artwork photo frame, thin aluminum plate artwork carving pattern.

3. Other wood products field:
speakers, game consoles cabinets, computer tables, sewing machine table, musical instruments, balustrade, furniture legs, stair railing ,cylinder items, handrail, desk or chair legs,3D cylinder mold, and a variety of rotational symmetry; Insulation, plastic chemical components, PCB, car body, ABS, PP, PE, etc.

1.High efficiency:
Multiple spindle motor work separate, saving tool changing time, can complete large quantity product
processing. Advanced automatic tool changer, without
2.High engraving speed:
Adopting high- speed drive stepper (or servo) motor and drive, Y axis using a dual motor drive, high precision rack drive, with the strong cutting of the
3.Stable operation:
adopts imported linear square guide rail, double row and four ball slider, loading capacity, smooth operation, high precision, long service life, imported ball screw and high precision, the knife accurate.

Packing & Delivery


Company Profie

Shandong Guandiao CNC Equipment Co., Ltd is an innovative enterprise engaged in research and development, production, sales and good after- sales service. The company's main products include Panel furniture CNC cutting machine, Woodworking CNC Machining Center, CNC router, Multi-head cylinder CNC engraving machine, Styrofoam CNC router, 3D scanner, Vacuum membrane press machine,Vacuum forming machine, Laser engraving and cutting machine, etc. Products applied to the panel furniture, European furniture,solid wood furniture, advertising, stone, building decoration, handicrafts, mold making, staircases column, PCB printing,automotive industry, packaging industry, shipbuilding, wood manufacturing, watches and clocks, accessories, seals and other industries.
After nearly 10 years of development, the company has a perfect technical team, clear labor division, ensuring the high quality products sent to the whole country, to the world.


Our Services

1. Delivery and Lead time
Machine will be proper packed and loaded in container, as multiple loaded to save space or wooden carton sealed for better transportation.
Machine will be tidy and clean , with anti rusty oil brushed on mechanical parts to prevent rusty on sea transportation.
A series pictures and videos will provided as machine finished for help customer understand the performance of the machine.
2.Warranty:
Machine warranty is 12 months.  Machine as normal using and maintenance condition, if get any problem, will provide spare parts for free.  Out of warranty, will collect the accessories cost. Technical support for maintenance or fix on time and all the time.
3. Technical support:
Manual and video illustration of the machine will be provided
24 hours online by Ali Trademanager, Skype, Email, QQ, or telephone
Technical support by email, whatsapp, wechat,imo and skype available on time.
4.After sale service:
Normally the machine will sent on whole except the machine is over size to load container.  so the machine arrange in production immediately after get electricity (air and water some model needed).
The video for operation will provide.
Training at our workshop or on site is available.After sale-service
5.We accept the ODM,OEM

 If you have other needs, please let me know
