• Model NO.：BSGR-R-P
• Color：Iron Grey
• Working Application：Plywood,Blockboard,Particleboard
• Working Voltage：380V,415V,440V and So on
• Transport Package：Container
• Specification：3140*2770*2440mm
• Trademark：METRO
• Origin：China
• HS Code：8465930000
• Production Capacity：500sets,Year

BSG1313R-R-PSanding width(Max)1300mmSanding Thickness2.5-110mmSanding Length>780mmAbrasive belt dimension1330X2620mmFeed Speed20-50,50-80m/minAbrasive belt Speed20,20,24m/sMotor for sanding head #130kwMotor for sanding head #222kwMotor for sanding head #318.5kwMotor for feed7.5kwMotor for brush0.75kwMotor for lifting0.75kwTotal Capacity of motors79.5kwPower supply380v 50HzOperating pressure0.6-0.8MPaCapacity of suction extraction7900m³/hDimension (LxWxH)3140X2770x2440mmNet Weight9800kgs3. More Pictures




4. Service:
Pre-sale services:
1) Provide the free consultation of the equipment
2) Provide the standard device and the flow chart
3) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
4) Welcome to visit our factory
Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.
After sale services:
1) 24 hours online service
2) Provide the video  with Install and debug the equipment
3) Provide technical exchanging

Welcome to Contact
