• Model NO.：DW1325
• Customized：Customized
• Condition：New
• Color：Customized
• Spindle Power：2.2kw Water Cooling
• Optional：Air Cooling Spindle
• Size of The Machine：Accept Customized
• Machine Structure：Customize Accepted
• Machine Body：Cast Steel
• Table：T-Slot or Vacuum Table or Both
• Machine Transmission System：Can Be Customized According to Your Need
• OEM Service：Accepted
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE
• Trademark：dwin made in china
• Origin：Jinan, Shandong, China
• HS Code：846599
• Production Capacity：50 Sets Per Month

NO.
Description
Parameter
1
X,Y,Z Working Area
1300x2500x200mm
3
X,Y,Z Traveling Positioning Accuracy
±0.03/300mm
4
X,Y,Z Repositioning Positioning Accuracy
±0.05mm
5
Lathe Structure
Welded Structure
6
X, Y Structure
Gear Wheel Transmission, Shaft Linear Bearings
7
Z Structure
Ball Screw, Shaft Linear Bearings
8
Max. Consume power
3.5Kw
9
Max. Speed
0-32000mm/min
10
Max. Working Speed
0-20000mm/min
11
Spindle Power Motor
2.2KW / 3.0kw water-coolant Spindle
12
Spindle Speed
0-24000RPM
13
Drive Mode
Stepper Motor
14
Working Voltage
AC220V/380V, 50/60Hz
15
Command
G Code, *uoo, *mmg, *plt
16
Operating System
DSP System (Option: Mach3 PC Software)
17
Interface
USB
18
Flash Memory
128M
19
Collet
ER20
20
X,Y Working Delicacy
<0.01mm
21
Software
Type3,  Ucancam,  Artcam
22
Running Circumstance
Temperature: 0°C~45°C  Relative humidity: 30%~75%
23
Packing Size
Separated: 3200X1950X1404mmIntegrated: 3200X1950X1950mm
24
Gross Weight
900KG
Applications:
It is suitable for mass processing of solid woods, MDF, Composite boards, Alucobond, PVC, Rigid plastics, Acrylic Sheets, Glass, Organic glass, Aluminum plates and other materials.

~Furniture Industry
~Decoration Industry
~Musical Instrument Industry
~Mould Industry
~Advertising Industry



 Aftersale Service :
1. One year quality guaranty, the machine with main parts (excluding the consumables
)shall be changed free of charge if there is any problem during the warranty period.

2. Lifetime maintenance free of charge.

3.  Free training course at our plant.

4.We will provide the consumable parts at an agency price when you need replacement.

5.18 hours on line service each day, free technical support.

Machine has been adjusted before delivery.
We provide English operation manual and video to help you to learn the machine.

We are a manufacturer of all kinds of CNC machines, like CNC Wood engravers, CNC Stone engraversand CNC Plasma cutting with well-equipped testing equipment and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in advertisement industry and other industries.

FAQ
1,How about the documents after shipment?

After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and  other certificates as required by clients.

2,How long is the delivery time?

For standard machines, it would be 7-10 days; For nonstandard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
