Lathe CNC Router Wood Price, Woodworking CNC Router Machine
Jinan Firm CNC Equipment Co., Ltd.- Type：Engraving Router
- Spindle Layout：Spindle Over
- Spindle Number：Single-Spindle
- Feed Mode：Mechanical
- Controlling Mode：CNC
- Certification：CE, ISO
Base Info
- Model NO.：FM1325
- Customized：Customized
- Condition：New
- Color：Customized
- Machine Size(mm)：Machine Size
- Table Size(mm)：1800*3100
- Engraving Area：1300*2500*200
- Spindle Power：3.0kw Water Cooling Spindle
- Spindle Rotate(Rpm)：6000~24000
- Motor：Stepper ,Servo
- Driver：Leadshine
- Guide：Taiwan Hiwin Linear Guide
- Transmission：Helical Rack and Pinion
- Control System：DSP,Nc Studio
- Transport Package：Standard Export Wooden Case
- Specification：CE, SGS, ISO
- Trademark：FIRM
- Origin：Shandong, Jinan
- HS Code：84659900
- Production Capacity：300sets,Year
Description
1300*2500*200Engraving area
(W*L*thickness)(mm) Working Form Full-automatic Spindle Power 3.0KW water cooling spindle Spindle Rotate(rpm) 6000~24000 Motor Driver Stepper motor (Chinese servo motor or imported servo motor is optional) Tool Diameter(mm) Ø3.175,Ø4,Ø6, Ø12.7mm Machine Structure Industry square tube structure Transmission System Imported ball screw or high accuracy gear rack X,Y,Z Rail Imported square rail Mechanical Accuracy <0.03/300mm Engraving Speed(mm/min) 8000~12000mm/min Feeding Speed manual Data Transmission PC connect Support Format G code or HPGL Working Voltage AC220V/50Hz or 380V/50Hz Support Format G Code or HPGL Range of Application Woodworking relief engrave ,Cutting , Hollow Machine Net Weight 1200Kg
Package:
1. Water-proof plastic film package with foam protection in each corner.
2. Solid Seaworthy Wood Box Package with Steel Belt.
3. Save space as much as possible for container loading.
Contact information
(W*L*thickness)(mm)
Package:
1. Water-proof plastic film package with foam protection in each corner.
2. Solid Seaworthy Wood Box Package with Steel Belt.
3. Save space as much as possible for container loading.
Contact information
JINAN FIRM CNC EQUIPMENT CO.,LTD
A-505Jingliu Road, Huaiyin District, Jinan City, Shandong Province, China.
Tel: 0086-0531-69986330 Fax : 0086-0531-69986330
Website: http://firmcnc.en.made-in-china.com, http://firmcnc.en.made-in-china.com
firmcnc.en.made-in-china.com
Cell phone: +86-13954117091
Why choose us?
1.All spare parts in stock.
2.Machine more than 20 sets different configuration in stock.
3.Professional technician have more than 10 years experiwnce.
