• Model NO.：DW1325
• Customized：Customized
• Condition：New
• Color：Customized
• Rotary：Attached
• OEM：Accept
• Model：Dw325
• Products：CNC Router
• Controller：DSP,Weihong Card,Mach3
• Warranty：18 Months
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE, SGS
• Trademark：DWIN
• Origin：Jinan, Shandong, China
• HS Code：846599
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. DW1325 Customized Customized Condition New Color Customized Rotary Attached OEM Accept Model Dw325 Products CNC Router Controller DSP/Weihong Card/Mach3 Warranty 18 Months Transport Package Plywood Box, Free From Fumigation Specification CE, SGS Trademark DWIN Origin Jinan, Shandong, China HS Code 846599 Production Capacity 50 Sets Per Month

Product Description

                                              Hot Sale Rotary CNC Router Machine (DW1325)

This cnc router attached rotary device on the machine, can be used for 3d cylinder material engraving, can also be widely use in other industry

Two Heads 3D CNC Router with Rotary Axis

Product overview:

This series is at service of three dimensional cylinder engraving .Machine configuration is changed from materials.Ordinary series mahines can also added the rotary device to engraving the cylinders.

Product Features:

1.360° cylinder engraving. Expands the application of CNC router .can applicable in the furniture and gifts industry .

2.Cylinder materials is fixed by chuck thought three holders,force ecerted uniformly and effectively ,and center positioned accurately ,so guarantee the working accuracy.

3.Rotary's diameter and length can be customized.

4. The machine has the adantages of break point and break power continue engraving.

Parameter details :


XY working area	1300mm x2500mm x 200mm
Z working area	200mm
Table size	2100mm*3100mm*1750mm
Max feeding	4m-5.5m/min
Work-holding	2m-3m/min
Resolution	0.005mm
Interface	USB
Command	G code*.u00*.mmg*.plt
Surroundings for software	Windows98/2000/xp
Power(not include the spindle)	500W
Working voltage	AC220V/50Hz
spindle power rate	2.2KW water cooling
spindle rotating speed	0-24000rpm/min
Drive motor	steper

Applicable:
1. Cylindrical or three-dimensional engraving on stone,wood,metal and advertising industry.
2. Advertisement: Engraving and cutting of various labels and number plate, marble, etc for artistic effects on materials including marble, brass, steel, and other metallic material.
3. Crafts: Engraving characters of any language and patterns on gifts and souvenirs, primitive processing and shaping of artistic crafts, and stiletto.
4. Moulding: Engraving delicate letter and flower pattern, primitive and fine processing of the small mould.
5. Architectural models: Engraving fine window, fencing and wall patterns, etc.
6. Seal: Engraving seals and medal on materials such as buffalo horn, wood etc.
7. Label: Engraving character, number, and other pattern on label for products and on product directly.
8. Wood processing: Processing density board, stiletto for surfing board, processing of marbles, cabinet and furniture.

Dwin kindly tips:
All the parts of machine can do some changes to meet your requirements.
1.motor (step motor or servo motor optional)
2.spindle (air cooled or water-cooled optional )
3.guide rail (round guide rail or square linear guide optional )
4.the table of the machine (Vacuum table,T-shot table,Combination of T-shot &Vacuum table,Normal table,Table moving)

Guarantee & after sale service :
1) Guarantee for 1.5 years
2) Free training to make sure you master the operating of cnc router (on internet or by telephone)
3) 24hour technical supporton Internet or by Telephone, free instructions and problem solving
4) Video CD for machine using and maintaining
