Base Info
- Model NO.：MFB320
- Function：Gluing, End Trimming, Fine Trimming, Buffing
- Type：Linear Edge Banding Machine
- Edging thickness：0.4-3mm
- Automatic Grade：Semiautomatic
- Panel Feeding Speed：13m,min
- Certification：CE, ISO
- Panel Thinkness：10-40mm
- Min.length panel：300mm
- Min.width panel：60mm
- Manufacturing Principles：Glue Tank Underneath
- Customized：Customized
- Edging Belt Width：12-45mm
- Transport Motor：0.75kw
- Glue Post Motor：0.37kw
- Polishing Motor：0.18kwx2 1400r,Min
- Glue Tank Heating Power：1.5kw
- Air Pressure：0.7MPa
- Total Power：4.08kw ,4.48 Kw
- Overall Dimensions：2370*850*1460mm
- Packing Size：2450*950*1550mm
- Net Weight：700kg
- Trademark：STEELER
- Transport Package：Stretch Film or Wooden Case or Customized
- Specification：2370*850*1460mm
- Origin：China
