• Model NO.：DW-1325
• OEM：Accepted
• X Y Working Area：1300*2500 Cm
• Z Working Area：120mm
• Max Travel Speed：8000mm,Min
• Max Engraving Speed：6000mm,Min
• Spindle Roating Speed：0-24000rpm,Min
• Work Mode：Stepper Motor , Servo Motor
• Type：Engraving Router
• Spindle Layout：Vertical
• Spindle Number：Single-Spindle
• Feed Mode：Manual
• Controlling Mode：CNC
• Customized：Customized
• Color：Customized
• Transport Package：Plywood Box, Free of Fumigation
• Specification：CE, FDA
• Trademark：DWIN
• Origin：Jinan City, Shandong Province
• HS Code：8465990000
• Production Capacity：200 Sets Per Month

Technical parametersModelDW-1325 cnc routerWorking area4ft x 8ft/1300*2500mmTable size4.75ft x 9ftTable structureT-slot table (vacuum optional)Working accuracy0.05mmRepositioning accuracy0.05mmTransmissionX and Y by rack and pinion, and Z by screwMax. No-load speed17m/minMax. Working speed12m/minSpindle power3.0KW/4.5KWSpindle speed0-24000RPMPower supplyAC220V/50-60HzCommandG code/mmg/plt/Controlling systemMach3/ DSP, etcDimension1700*3100*1500mmTotal weightApprox. 1000kg
Dwin kindly tips:
All the parts of machine can do some changes to meet your requirements.
1.motor (step motor or servo motor optional)
2.spindle (air cooled or water-cooled optional )
3.guide rail (round guide rail or square linear guide optional )
4.the table of the machine (Vacuum table,T-shot table,Combination of T-shot &Vacuum table,Normal table,Table moving)

Guarantee & after sale service :
 1) Guarantee for 1.5 years
2) Free training to make sure you master the operating of cnc router (on internet or by telephone)
3) 24hour technical supporton Internet or by Telephone, free instructions and problem solving
4) Video CD for machine using and maintaining

Welcome to contact us for more details!
