• Model NO.：1325
• Table：Aluminum T-Slot Table with PVC
• Spindle：3,4.5,5.5,6,7.5kw
• Control System：Ncstudio,Mach3,DSP
• Inverter：Fuling Inverter
• Motors：Stepper Motors
• Drives：Stepper Drives
• Software：Artcam
• Guide Rail：Hiwin Linear Square Guide Rail
• Oiling System：Yes
• Transport Package：Plywood Case
• Specification：3300*1950*1950mm
• Origin：China
• HS Code：8465990000
• Production Capacity：500 Sets,Year

Overview Product Description

Detailed PhotosSamples



Product ParametersMachine model1325/1530/2030/2040Working area1300x2500mm/1500x3000mm/2000x3000mm/2000x4000mmMachine structureWelded steel tube,cast iron vertical shafts and steel gantryTableAluminum T-slota table with PVCSpindle3.0kw water cooled spindleSpindle speed0-24000rpmColletER20Guide railHiwin linear square guide railDriving methodX,Y by gear rack,Z by ball screwControl systemNcstudio control systemMotors&drivesStepper motor 450B and Leadshine MA860H driveInverterFuling inverterMax.Idling speed25m/minMax.working speed12m/minWorking accuracy<0.05/300mmInstruction formateG code*.u00*.mmg*.pltWorking voltageAC220V/AC380V,single phase or three phase,50/60hzControl cabinetIndependent control cabinetOthersTool box,oiling system,water pump,tool sensor,English manualOptions1,4.5kw/5.5kw water cooled spindle;
2,3.5kw/4.5kw/6.0kw/7.5kw air cooled spindle
3,Mach3 USB control system
4,DSP controller
5,Rotary axis
6,Dust collector
7,Vacuum table with 5.5kw vacuum pump
8,Oil mist cooling system CertificationsPackaging & Shipping

Packge: Plywood case with water proof materials;3300*1950*1950mm;1200kg
