• Model NO.：GBX218
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Transport Package：Disc Chipper No Packing or Customed
• Specification：2300*2150*1500mm
• Trademark：Yufchina
• Origin：Henan, China (Mainland)
• HS Code：84659600
• Production Capacity：30 Set,Sets Per Month

Basic Info.

Model NO. GBX218 After-Sales Service Provided Engineers Available to Service Machinery Overseas Transport Package Disc Chipper No Packing or Customed Specification 2300*2150*1500mm Trademark Yufchina Origin Henan, China (Mainland) HS Code 84659600 Production Capacity 30 Set/Sets Per Month

Product Description

Forestry Machinery wood chipper machine for log wood
we have two types , one is drum wood chipper, the other is disc wood chipper, for drum wood chipper details, as below :







Wood chipper Technical Parameter:

Model	GBX215	GBX216	GBX218	GBX2110	GBX2113
output capacity (t/h)	5-8	8-12	10-20	15-25	25-35
blade qty (pcs)	2 or 3	2 or 3	3 or 4 or 5	3 or 4 or 5	3 or 4 or 5
main motor power (kw)	45	55	110	132-160	220
feeding motor power (kw)	2.2-3	3-4	4-5	7.5-11	11
rotor dia. (mm)	500	600	800	1000	1300
feed inlet size (mm)	160*400	230*500	300*680	500*1000	500*700
rotary speed of rotor (rpm)	590	590	650	500	500
feeding speed (m/min)	38	38	38	38	38
max. log dia.(mm)	160	200	300	420	450
wood chips size (mm)	20-35	20-35	20-35	20-35	20-35
feed conveyor power (kw)	2.2	4	4	11	11
discharge conveyor power (kw)	2.2	3	5.5	5.5	7.5
weight (kg)	2990	4070	7200	12500	14500
dimension (mm)	1540*1240*1020	1980*1950*1250	2300*2150*1500	3850*2448*2050	3850*2448*205

Discription of drum wood chipper
1. drum wood chipper is the preparation of a variety of high-quality wood and special equipment, used in paper mills, particle board plant, wood fiberboard factory production and export base.
2. You can log, wood and other cutting trails degree uniform growth, cut flat, uniform thickness of high-quality industrial wood, you can cut the branches, plates and so on.
Machine Advantage
1. Advanced structure, high quality cutting chippers, wide scope of application, simple operation, easy maintenance;
2. Wear-resistant sharp alloy tool, reliable advanced and to enhance its service life;
3. Wearing parts low-consumption, low running cost.

Our Services
Pre-sale
We adhere to the principle of acquiring maximum profit at minimum investment,while meeting the needs of each customer.
During-sale
We have production progress report each week with detailed description and photos, including raw materials tables, process and deep process records, testing data sheest, etc.
After-sale
Warranty period of the equipment is 1 year.During the warranty period, the damage caused by non-human factor, YUFENG will be responsible for the repair or replacement.
