• Model NO.：DW4040
• Customized：Customized
• Condition：New
• Color：Customized
• Model：Dw4040 Mini CNC Router
• Machine Body：Whole Cast Iron
• Work Dimensions：400 X 400 X 120mm
• Max.Speed：4, 200mm,Min
• Working Speed：0-3000mm,Min
• Software：Type 3, Artcut, Artcam
• Max. Power Consumption：900W
• Drive Motor：Stepper Motor
• Spindle：1.5kw Variable Speed, Water Cooled Motor
• Warranty：18 Months
• Transport Package：Plywood Box, Free of Fumigation
• Specification：CE, SGS
• Trademark：DWIN
• Origin：Jinan City, Shandong Province
• HS Code：846599
• Production Capacity：150 Sets Per Month

Machine body:
Whole cast iron
Work dimensions:
400 x 400 x 120mm
Body dimensions:
700 x 700 x 800mm
Z-axis working area:
120mm
Max. Feeding height:
120mm
Cut thickness of material:
<20mm
Max.Speed:
4, 200mm/min
Working speed:
0 - 3, 000mm/min
Mechanical precision:
0.01mm
Software:
Type 3, Artcut, Artcam

Max. Power consumption:
900W
Power supply :

AC 220/50Hz for your
need
Driver type:
Stepper motor
Memory:
1MB
Spindle:

1.5KW variable speed, water cooled motor
Spindle speed:
0 - 24, 000rpm
Blade diameter:
1 - 6m
Control system:

Artcut or Wei hong  (NCSTUDIO) or DSP (USB interface)
Command:
G code, u00, mmg, plt
Interface:
RS232
Running circumstance temperature:
0 - 45
Relative humidity:
30% - 75%

 Guarantee & after sale service :
 1) Guarantee for 1.5 years
2) Free training to make sure you master the operating of cnc router (on internet or by telephone)
3) 24-hour technical supporton Internet or by Telephone, free instructions and problem solving
4) Video CD for machine using and maintaining
