Woodworking Plywood Trimming Saw Machine with Edging System

Linyi Sin San Lin Smart Machinery Co., Ltd.
  • Type：Table Panel Saw
  • Power Type：Electric
  • Layout：Horizontal
  • Controlling Mode：CNC
  • Automatic Grade：Automatic
  • Precision：High Precision

Base Info

  • Model NO.：ABC3125
  • Certification：CE, ISO, FDA
  • Customized：Customized
  • Condition：New
  • Color：Customized
  • Cutting Length：1220mm-1240mm
  • Cutting Width：2440mm-2460mm
  • Cutting Thickness：3-60mm
  • Weight：6t
  • Transport Package：Stretch Film Packaging
  • Trademark：METRO
  • Origin：China
  • HS Code：8465910000
  • Production Capacity：100set,Month

Description

Techanical Data:Cutting length1220mm-1240mmCutting width2440mm-2460mmCutting thickness3-60mmDiameter of saw blade305*25.4   120TeethLongitudinal direction speed1-30m/min(adjustable)Lateral direction speed1-30m/min(adjustable)Longitudinal motor power16.5kwLateral motor power19.4kwLongitudinal conveyor power1.5kwLateral conveyor power2.2kwLongitudinal edge sanding4.4kwLateral edge sanding4.4kwAutomatic pushing deviceCylinder automaticSquare tube thickness160*6(national standard)Material of line guide45# round steelDiameter of round steel45#Material of platenPressure platenScissor lift motor3kwTotol motor39kw(Equipped with edging system total power 48kw)Scissor lift capacity2 TControl systemWeihong PLCElectric units380V/415VWorking methodManual upper plate, automatic lower plateWeight 6TWoodworking Plywood Trimming Saw Machine with Edging System

Woodworking Plywood Trimming Saw Machine with Edging SystemWoodworking Plywood Trimming Saw Machine with Edging System

Pre-sale Service:
1) Provide the free consultation of the equipment
2) Provide the standard device and the flow chart
3) According to the clients' special requirement, offering the reasonable plan and free design to help to select the equipment.
4) Welcome to visit our factory

Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea install and debug the equipment
3) Train the first-line operator.

After Sale Service:
1) 24 hours online service
2) Provide the video  with Install and debug the equipment
3) Provide technical exchanging
