Woodworking Machinery

Mj2700 China Manufacturer CNC Panel Saw Woodworking Machine

Qingdao Zhongding Machinery Co., Ltd.
  • Type:CNC Saw
  • Power Type:Electric
  • Layout:Horizontal
  • Controlling Mode:CNC
  • Automatic Grade:Automatic
  • Precision:High Precision

Base Info

  • Model NO.:MJ2700
  • Certification:CE, ISO
  • Customized:Customized
  • Condition:New
  • Color:Iron Grey
  • Transport Package:Plywood Case
  • Specification:5500*5600*1700mm
  • Trademark:ZD
  • Origin:China
  • HS Code:84659100
  • Production Capacity:2 Sets,Week

Description

ModelMJ2700MJ3300MJ3800Sawing length2700mm3300mm3800mmSawing thickness85/100/120mm85/100/120mm85/100/120mmDia. of main saw blade355/400/460mm355/400/460mm355/400/460mmAxis dia. of main saw blade30/60mm30/60mm30/60mmRotate speed of main saw blade3950/4500rpm3950/4500rpm3950/4500rpmDia. of grooving saw blade180mm180mm180mmAxis dia. of grooving saw blade25.4/30mm25.4/30mm25.4/30mmRotate speed of grooving saw blade6300rpm6300rpm6300rpmSaw carriage forward speed0-120m/min0-120m/min0-120m/minSaw carriage back speed60-120m/min60-120m/min60-120m/minHead saw motor7.5/11kw7.5/11kw7.5/11kwGrooving saw motor1.5kw1.5kw1.5kwSaw carriage drive motor2.2kw2.2kw2.2kwAutomatic feeding motor1.2kw2kw2kwPusher motor2kw2kw2kwHigh pressure blower motor2.2kw2.2kw2.2kwTotal power17/21kw21/27kw21/27kwAutomatic feeding speed0-120m/min0-120m/min0-120m/minOperation pressure5-7kg/cm5-7kg/cm5-7kg/cmWorkbench height950mm950mm950mmNet weight5000kg6000kg7000kgDimensions5500*5600*1700mm6100*6200*1700mm6700*6800*1700mm

Other popular machines:

Mj2700 China Manufacturer CNC Panel Saw Woodworking Machine
Mj2700 China Manufacturer CNC Panel Saw Woodworking Machine
Mj2700 China Manufacturer CNC Panel Saw Woodworking Machine
Mj2700 China Manufacturer CNC Panel Saw Woodworking Machine

For more details, pls free to contact us.
