• Model NO.：2400
• Panel Thinkness：10-60mm
• Min.length panel：120mm
• Min.width panel：80mm
• Manufacturing Principles：Glue Tank Overhead
• Customized：Customized
• Voltage：220V 380V
• Model：2400 Edge Banding Machine
• Keywords：Woodworking Edge Banding Machine
• Core Components：Pressure Vessel
• Key Selling Points：Easy to Operate
• Warranty：1 Yaer
• Heating Power：0.75kw
• Feeding Motor Power：0.75kw
• Fine Trimming Motor Power：0.75kw*2
• Plishing Motor Power：0.18kkw*2
• Glue Spreading Motor Power：0.37kw
• Air Pressure：0.7MPa
• Machine Size：4500*900*1500mm
• Weight：2200kg
• Total Power：10kw
• Transport Package：Plywood Case
• Specification：4500*900*1500mm
• Trademark：Guandiao
• Origin：Shangdong, China
• HS Code：8465990000
• Production Capacity：10000pieces,Year

Model

GD-2400

Edge Thickness

0.4-3mm

Working width of panel

15- 55 mm

Feed Speed

13m/min

Min Panel Length

120mm

Min Panel Width

>80mm

Motor Power

10kw

Working Pressure

0.7Mpa

Weight

2200kg

Voltage

380v

Advantage:

1. Adopt imported motor and high quality electrical component.

2. Product serialization and diversification is easy for the customer to choose.

3. High precision and work efficiency.

4. Automatic and precise gluing procedure as well as integrated double finish.

5. High strength frame structure, durable

6. Glue evenly, conveying stability

7. The machine is equipped with hand lubricator to reduce wear

Application:

Edge banding machine is used to cover the exposed sides of materials such as plywood, particle board or MDF, giving the appearance of a solid (or more valuable) material. Can also be used instead of features such as face frames or molding.


Packing and shipping

Packing Details: Seaworthy packaging or according to customer requirements.


FAQ

1. This is the first time I buy the machine, is it easy to operate?

   A: We can provide the operation manual or video for guiding. If it is hard for you learning, we can also help you by "Team viewer" online, with telephone or Skype explain.

2. ARE YOU TRADING COMPANY OR MANUFACTURER ?

   A: We are factory.

3. Can I visit your factory?

   A: Yes! We greatly welcome customers to visit our factory!

4. What is your MOQ?

   A: Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.

If you have any question, please contact me anytime
