• Model NO.：BG183A
• Heat Source：Boiler
• Transport Package：Container
• Specification：2300x5200x4100mm
• Trademark：METRO
• Origin：China
• HS Code：841932000
• Production Capacity：50set,Month

Basic Info.

Model NO. BG183A Heat Source Boiler Transport Package Container Specification 2300x5200x4100mm Trademark METRO Origin China HS Code 841932000 Production Capacity 50set/Month

Product Description

Product Description

Plywood Net Dryer Machine for Face Veneer Drying1. MAIN FEATURES:
1. The machine is usually designed and customized according to user 's requirement (such as veneer size,drying capacity, workshop space ).
2. Mainly used to remove extra moisture from the veneer.
3. The heat medium can be thermal oil or hot steam.
4. Roller gear drive system help keep the dryed veneer smooth and flat.
5. Speed adjustable according to different veneer MC and veneer thickness.

2. TECHNICAL SPECIFICATIONS:

Machine model	BG183A
Density	550Kg/m3
Veneer thickness range	1.5-3.6mm
Initial moisture content	80%
Final moisture content	10%
Load ratio	80% to 85%
Woking width	2650mm
Working decks	3decks
Length of heating section	2000mm x 8 sections
Length of cooling section	2000mm x 1 section
Transmission speed	0-15m per min
Drying capacity	3-4m3 per hour
Steam consumption	2100kg per hour
Installation motor power	107kw
Transmission motor power	4Kw x 3sets
Ventilation motor power	11Kw x 8sets
Cooling motor power	7kw
Machine oveall dimension	23970×5150×4460mm
Machine net weight	60000Kgs

3.More Pictures:
