Large Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture

Linyi Chaoda International CNC Technology Co., Ltd.
  • Type：Engraving Router
  • Spindle Layout：Vertical
  • Spindle Number：Single-Spindle
  • Feed Mode：Mechanical
  • Controlling Mode：CNC
  • Certification：CE, BV, TUV, SGS

Base Info

  • Model NO.：JC4050-5AXIS
  • Customized：Customized
  • Condition：New
  • Color：Customized
  • Product Name：5 Axis CNC Router Machine to Make Wood Sculpture
  • Structure：Thick Steel Wall Structure
  • Table：T-Slot with Clamps
  • Working Area：4000X5000X2000mm
  • Driving System：Servo Motor and Driver
  • Option：Rotary Axis
  • Transport Package：Wrapped with Protection Film,Fasten by Metal Wires
  • Specification：customized
  • Trademark：CHAODA
  • Origin：China

Description

Model No.JC4050-5AXISX,Y,Z,A,C working size4000*5000*2000mm* ±120°* ±245°Whole structureheavy duty steel wall structureTable surfaceT slot with clamps (option: vacuum table)Spindle10KW ATC spindle, cooled by liquidTool magazine Disk type automatic tool changer, with 8pcs tool magazine Driving systemJapan YASKAWA servo motor and driverInverterDeltaOperating system5 axis Syntec (option:OSAI) Operation languageG codeWorking voltageAC380V, 3-phase, 50HzRunning environmentTemperature: 0ºC-45ºC; Relative humidity:30%-75%Large Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture

It can process many materials,like eps foam,woods, MDF, Composite boards, Alucobond,PVC, Rigid plastics,polyester,
fiberglass, Acrylic,Organic glass, Aluminum,etc.
Large Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture
Large Size 5 Axis CNC Router Machine to Make Big 3D Wood SculptureLarge Size 5 Axis CNC Router Machine to Make Big 3D Wood SculptureLarge Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture

Large Size 5 Axis CNC Router Machine to Make Big 3D Wood SculptureLarge Size 5 Axis CNC Router Machine to Make Big 3D Wood SculptureLarge Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture
Large Size 5 Axis CNC Router Machine to Make Big 3D Wood Sculpture
1. Sample testing before shipment
2. Provide 2 days free training for each machine
3. 12 months warranty for each machine
4. Friendly English version manual and operation videos for studying
5. Free technical support by phone,email,chatting or remote
6. Engineers available to service machinery overseas
