Mini CNC Router Engraving Machine for Jade Acrylic Wood Stone

Jinan Chanke Mechanical Equipment Co., Ltd.
  • Condition:New
  • Certification:CE, ISO, SGS, FDA
  • CNC or Not:CNC
  • Working Size:300X300mm
  • Machine Colour:Red or as Your Choice
  • Water Cooling Spindle Power:1.5kw

Base Info

  • Model NO.:CK3030
  • Rotary or Not:It Can But as Custom′s Choice
  • Motor:Stepper Motor
  • Compatible CAD/Cam Softwares:Type3 , Artcam ,
  • Working Voltage:AC220V50Hz or as Your Local Coltage
  • Work off-Line:off Line Working DSP
  • Accessories:Collets, >20 Cutterser25
  • Lathe Bed:Steel Lathe Bed
  • Type:Engraving Router
  • Spindle Layout:Spindle Over
  • Spindle Number:Single-Spindle
  • Feed Mode:Manual
  • Controlling Mode:CNC
  • Customized:Customized
  • Color:Red
  • Transport Package:Plywood Packing
  • Specification:iso ,SGS,FDA,CE
  • Trademark:chanke
  • Origin:Shandong
  • HS Code:847989999
  • Production Capacity:50sets,Months

Description


1Machine bodyWhole cast iron2Work dimensions300 x 300 x 45mm3Body dimensions600 x 600 x 600mm
4
Z-axis working area45mm5Max. Feeding height60mm or bigger6Cut thickness of material<20mm7Max.Speed4, 200mm/min8Working speed0 - 3, 000mm/min9Mechanical precision0.01mm10SoftwareType 3 software, Artcut software, Artcam software11Max. Power consumption900W12Power supplyAC 220/50Hz for your need13Driver typeStepper motor14Memory1MB15Spindle1.5KW variable speed, water cooled motor16Spindle speed0 - 24, 000rpm17Blade diameter1 - 6m18Control systemArtcut or Wei hong  (NCSTUDIO) or DSP (USB interface)19CommandG code, u00, mmg, plt20InterfaceRS23221English LCDyes22Running circumstance temperature0 - 45 °c23Relative humidity30% - 75%
 6. Packing of Machine
Water-proof plastic film package with foam protection in each corner.
Solid Seaworthy Wood Box Package with Steel Belt.
Save space as much as possible for container loading.


7. Guarantee & service of Machine
Guarantee:
Two years quality guaranty, the machine with main parts(excluding the
consumables) shall be changed free of charge when if any problem during the warranty period.
Service: ( Provide whole life technical support, 24h online )
Before sale:
We would always be here to provide any information you need at the first time,and give professional suggestions according to your real needs for free;
During sale:
We would deal with all the production and shipping affairs, after everything is ready, we would tell you everything goes well here;

After sale:

1) We would provide English Version working manual.
2) If you have any questions during using and maintaining, our engineers who could speak very good English would answer you online or by calls.
3) Machine warranty is one year. So if your machine has any unintentionall damages, we would provide parts for free.
4) If your machine has big problems if by any chance, our engineers would arrive there to debug and fix.
5) Could be remote control if needed.
