Metal Mould Engraving CNC Router Milling Machine Tool Tat-650
Suzhou Talent Import and Export Co., Ltd.- Condition：New
- Certification：ISO, CE
- CNC or Not：CNC
- Transport Package：Wooden Package
- Specification：650
- Trademark：TALENT
Base Info
- Model NO.：TAT-650
- Origin：Suzhou, China
- HS Code：8401200000
- Production Capacity：20PC,Month
Description
CNC engraving and milling machine parameters Project Unit TAT-650 TAT-660 TAT-760 TAT-8080 TAT-1080 X-axis travel mm 500 600 600 800 800 Y-axis travel mm 600 600 700 800 1000 Z-axis travel mm 260 260 350 400 400 Spindle nose to table mm 50-310 50-310 30-290 70-470 70-470 Three-axis guide width X/Y:30 Z:25 X/Y:30 Z:25 X/Y/Z:30 X/Y/Z:MSA35 X/Y/Z:MSA35 Table size mm 500*600 600*600 600*700 800*800 800*1000 T-slot mm 6*16*90 6*16*90 6*16*90 7*18*100 9*18*100 Max load capability kg 300 300 300 400 400 Standard spindle Motorized spindle Motorized spindle Motorized spindle Motorized spindle Motorized spindle Spindle speed rpm 3000-24000 3000-24000 3000-24000 3000-24000 3000-24000 Spindle power 5.5 5.5 Spindle taper ER25-32 ER25-32 ER25-32 ER25-32 ER25-32 Maximum cutting feed rate
(X/Y/Z) m/min 8 8 8 8 8 Rapid speed(X/Y/Z) m/min X/Y/Z:15 X/Y/Z:15 X/Y/Z:15 X/Y/:18 Z:15 X/Y/:18 Z:15 Ball screw diameter/pitch mm X/Y/Z:32/5 X/Y/Z:32/5 X/Y/Z:32/5 X/Y:40/6 Z:32/5 X/Y:40/6 Z:32/5 Positioning accuracy mm ±0.005/300 ±0.005/300 ±0.005/300 ±0.005/300 ±0.005/300 Repeatability mm ±0.003 ±0.003 ±0.003 ±0.003 ±0.003 Air pressure kgf/cm² 6 6 6 6 6 Net weight of machine kg 3200 3400 3600 4800 5300 Area mm² 1950*1895 1950*1895 1950*1895 2450*2150 2750*2150 Machine height mm 2355 2355 2355 2673 2673
(X/Y/Z)
