• Model NO.：RJ1325
• Customized：Customized
• Condition：New
• Max Engraving Speed：40000mm,Min
• Transmission：3.175, 6, 12.7
• Dust Catcher：3. 0kw
• Transport Package：Wooden Case
• Specification：1300x2500mm
• Trademark：Ruijie
• Origin：China
• HS Code：84609090
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. RJ1325 Customized Customized Condition New Max Engraving Speed 40000mm/Min Transmission 3.175, 6, 12.7 Dust Catcher 3. 0kw Transport Package Wooden Case Specification 1300x2500mm Trademark Ruijie Origin China HS Code 84609090 Production Capacity 100 Sets/Month

Product Description

Wood Working Center RJ1325

Features:
1. Welded structure by thick profiled steel, stabilized under high temperature, ensures minimum distortion., excellent rigidity and powerful strength.
2. Machine is mainly assembled with precise parts, Japanese YASKAWA servo motor makes machine stable running with low noise, high speed, and high accuracy. Italy HSD spindle makes machine with high precision and long service time and stable movement. Configured with imported tool magazine of 8 tools the machine can change tools speedy and freely. Tool sensor enables the machine compensate the tolerance of the tool length.
3. Automatic lifting device for vacuum suckers allows the easy operation for the job on the side of working pieces vacuumed working table with double cavities and Bakelite material with high absorption power.
4. Imported syntec high performance control system, separated keyboard control, color LCD display add machine more versatility.

After-Sale Service
1) The machine warranty is 1 year;
2) 24 hours technical support by email or calling;
3) Friendly English version manual and operation video CD disc.
4) Samples for free
5) CE/ISO certificate

Working Area	1300X2500X230mm
Max Moving Speed	60000mm/min
Max Engraving Speed	40000mm/min
Reposition Accuracy	< 0.05/300mm
Spindle	8KW Air Cooling
Transmission	Rack gear
Tool Diameter	3.175, 6, 12.7
Dust Catcher	3. kw
Vacuun	5.5kw
X, Y, Z Guide Rail	Linear Square Rail
Operation System	LNC control system
Voltage	AC 380V/50
