4 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 1325

Shandong Lintianzhiyuan CNC Equipment Co., Ltd.
  • After-sales Service：Available
  • Warranty：2 Years
  • Condition：New
  • Certification：ISO, CE
  • CNC or Not：CNC
  • Voltage：220V

Base Info

  • Model NO.：LT-6090
  • Model：Lt-6090
  • Name：CNC Router
  • Working Area：600*900*200mm
  • Table：Aluminum T-Slot Table with PVC
  • Spindle：1.5kw Water Cooled Spindle
  • Collet：Er16
  • Control System：Ncstudio Control System
  • Guide Rail：Hiwin Linear Square Guide Rail
  • Motors：Stepper Motors 86byg450b
  • Drivers：Stepper Drivers
  • Software：Artcam
  • Instruction Formate：G Code
  • Transmission：Tbi Ball Screw
  • Spindle Rotating Speed：24000rpm
  • Compatible Software：Coreldraw,Type3
  • Transport Package：Plywood Case
  • Specification：4.7cbm
  • Trademark：LINTCNC
  • Origin：China
  • HS Code：8465990000
  • Production Capacity：500

Description

Overview

Product Description


Product Parameters

NameCNC RouterModelLT-6090/LT-6012/LT-6015/LT-9012/LT-9015/LT-1218/LT-1224/LT-1325Working area600*900*200mmTableAluminum T-slot table with PVCSpindle1.5kw/2.2kw/3kw water cooled spindleColletER11/ER16/ER20Control systemNcstudio/Mach3 USB/DSP control systemGuide railHiwin linear square guide railMotors&driversLeadshine 86BYG-450B stepper motors&MA860 stepper driversTransmissionTBI ball screwSoftwareArtcam softwareCompatible softwareType3/Coreldraw/AutocadWorking voltageAC110V/AC220V,single phase,50-60HzOptionsRotary axis for round wood:80mm/100mm/150mm diameter;on table or by side
Water tank with water mist cooling system for metals

4 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 1325

Certifications



4 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 13254 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 13254 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 1325


Packaging & Shipping

4 Axis DIY 3030 4040 6090 Wood CNC Milling Cutter Router for MDF Oak Balsa Alucobond Aluminum Steel Iron PVC PCB Plastic Acrylic Atc 2.2kw 3kw Side Rotary 1325
