Automatic Finger Jointing Line with Feeding Length 120-900mm and Feeding Width 430-500mm/ China Wood Jointer Line Machine

Qingdao Xinlihui Machinery Co., Ltd.
  • Machine Item:Finger Jointing Line for Wood Brick
  • Machine Painting Color:Be Made According to Your Need
  • Price:More Competitive Price Than Other Competitors
  • Voltage:380V, 220V 50herz, Can Be Customized
  • After-Sales Service:24 Hours Technical Support by Email, Call, Video
  • Warranty Time:Offer Free Spare Parts and Service Within 12 Month

Base Info

  • Model NO.:MXB3518
  • Working Experience:Twenty Years′ Experience
  • Delivery Time:Quick Delivery in 20 Days
  • Max Working Width:590mm
  • Max Finger Joint Working Length:5000,6200mm
  • Certification:CE, ISO, FDA
  • Transport Package:Standard Package, Be Made According Cutomer Need
  • Specification:7300*1250*1600MM
  • Trademark:XINLIHUI
  • Origin:Qingdao City
  • HS Code:84659100
  • Production Capacity:100,Year

Description

Basic Info.

Model NO. MXB3518 Working Experience Twenty Years′ Experience Delivery Time Quick Delivery in 20 Days Max Working Width 590mm Max Finger Joint Working Length 5000/6200mm Certification CE, ISO, FDA Transport Package Standard Package, Be Made According Cutomer Need Specification 7300*1250*1600MM Trademark XINLIHUI Origin Qingdao City HS Code 84659100 Production Capacity 100/Year

Product Description

1, Application:

This machine used for waste wood recycling, will have an ear on construction sites and other regions, waste wood to open after the tooth comb, the glue wood machine pressure, can be achieved using length, this process of regeneration, wood can be used as a new wood, for the world to save energy and cost savings for the enterprise.

2,Technical parameters
Technical ParametersFiger jointer  Figer shaper
MXB3518A-B
Figer shaper
MXB3518C-C
Belt conveyor
Max working length 5000mm/6200mm150mm-900mm150mm-900mm900mm
Effective working width30mm-150mm590mm590mm590mm
Effective working length12mm-70mm18mm-150mm18mm-150mm18mm-150mm
Cutting saw rotary2840r/min4150rpm4150rpm
Fret saw motor  2840rpm2840rpm
rotary speed
Shaper spindle diameter 50mm50mm
Shaper spindle  6750rpm6750rpm
rotary speed
Shaper motor power 11kw11kw
Cutting saw motor2.2kw4kw4kw
Fret saw motor 0.75kw0.75kw×2pcs
Feeding motor power 0.55kw0.55kw×2pcs0.55kw×1pcs
Oil station motor power4kw2.2kw2.2kw
Working speed70m/min
Working air pressure0.8Mpa
Max oil pressure130kgs/c m²
Oil station motor power4kw
Frequency motor power 1.1kw1.1kw Frequency control
Machine dimension(6100×1250
×1600) mm (7300×1250
×1600) mm
(2800×1650
×1450)mm
(3300×1900
×1450)mm
(1700×730
×980)mm

3,Some pictures of machine for you:
Automatic Finger Jointing Line with Feeding Length 120-900mm and Feeding Width 430-500mm/ China Wood Jointer Line Machine
Automatic Finger Jointing Line with Feeding Length 120-900mm and Feeding Width 430-500mm/ China Wood Jointer Line Machine
4, Main Features:

1.Guide rail of finger joint shaper's conveyor is japan precision linear guide rail to gurantee the shaping accuracy .
2.The design for finger joint shaper is double blades+tooth-tenon knife assembly to  provide high precision.
3.The conveyor table of finger joint shaper adopts German pneumatic hydraulic conveyor system to control bakc and forth ,smoothly,low maintenance,high quality .
4.The second push part of finger joint assembler adopts long+short double pushing board design,
by this kind of structure ,it can assemble very short workpiece to reduce the cost .
5.Whole machine is conveniently operated by PLC Central integrated programmable controller.

5, Advantage:

1.Save wood and material cost

2. Semi-automatic production line greatly improves the working efficiency of workers and saves labor costs

3.Two people of the complete set of machinery can complete the operation, with low safety risk and low accident rate of work-related injury. In addition, the safety protection measures of the wood receiving machine are in place, making the whole operation safe and reliable.

Automatic Finger Jointing Line with Feeding Length 120-900mm and Feeding Width 430-500mm/ China Wood Jointer Line Machine
