Hwzl-S300 Wood Log Debarking Machine
CHANGZHOU HONGWEI IN-TECH CO., LTD.- Type：Debarking Machine
- Automatic Grade：Automatic
- Controlling Mode：Artificial
- Energy Saving：Energy Saving
- Certification：CE, ISO
- Warranty：1 Year
Base Info
- Model NO.：HWZL-S300
- Customized：Customized
- Condition：New
- Color：Multi Color
- Transport Package：Nude or Wooden Case
- Trademark：HWZL
- Origin：China
Description
wood log debarking machineModel HWZL-S300 HWZL-S600 HWZL-S800 Wood diameter (mm) 50-300 200-600 400-800 Wood length (m) 0.5-2 0.5-2 0.5-2 Capacity (TPH) 6-8 10-12 15-18 Debarking rate (%) Fresh log >95%
Dry log > 90% Fresh log >95%
Dry log > 90% Fresh log >95%
Dry log > 90% Roller diameter (mm) 275 530 710 Roller rotational speed (rpm) 230 200 180 Roller length (mm) 500 500 500 Power (kw) 7.5 x 2 15 x 2 30 x 2 Weight (T) 3.5 5.5 8 Size (L x W x H) (m) 6 x 1.6 x 1.55 6 x 2 x 1.8 6 x 2.5 x 2
Simple drawing
Wood log debarking machine is composed of five parts: debarking roller, feed port, bark discharging port, log discharging port and power drive device. It has separate bark discharging port and log discharging port, so it can work continuously and realizes continuous assembly line work from feeding to debarking and then log discharging.
