Wood CNC Engraving Machine 1325 Atc

Shandong Ruby CNC Equipment Co., Ltd.

Type：Engraving Router
Spindle Layout：Vertical
Spindle Number：Single-Spindle
Feed Mode：Mechanical
Controlling Mode：CNC
Certification：CE

Base Info

Model NO.：FX1325ATC
Customized：Customized
Condition：New
Color：Customized
Working Area：1300*2500mm
Control：Syntec Controller
Table：Vacuum Suction Table
Spindle Power：6kw,9kw
Transport Package：Plywood
Specification：1325atc
Trademark：FLYING
Origin：China
HS Code：84649090
Production Capacity：100PC,Month

Description

X, Y-AXIS TRAVEL1300*2500Z-Axis Travel300mmSpindle Power9kw HSD Air-cooling Spindle, 24000rpmRepeatability+/- 0.05mmMax. Rapid Travel Speed45m/minDrive System X and Y axisRack and Pinion, rail linear bearingDrive System Z axisBall Screw, rail linear bearingStandard Work Surfacealuminium T-Plate Extrusion Combined Bakelite Vacuum TableMotorServoWorking VoltageAC380V/50HZ, 220V/60HzCommand LanguageG Code & M CodeColletER32Tool ChangeBT30 ISO30, 8 PositionsOperating SystemNC Studio/Syntec control system
