• Model NO.：JCW1325R-4H
• Customized：Customized
• Condition：New
• Color：Green and White
• Name：4 Axis 4 Head Rotary 3D CNC Wood Carving Machine,
• Structure：Heavy Duty Steel
• Working Size：250mm Diameter; 1300mm Length
• Spindle：2.2kw Water Cooling
• Drive：Stepper Motor and Driver
• Inverter：Fuling
• Controller：DSP
• Xyz：Linear Square Guide Rail
• Xy：Rack and Pinion
• Z：Ball Sceww
• Working Voltage：3 Phase AC380V 50Hz
• Option 1：6,8,10,14 Heads
• Option 2：Flat Table
• Option 3：3D Scanner
• Option 4：Air Cooling Spindle
• Transport Package：Standard Wooden Case
• Specification：4 Axis 4 Head
• Trademark：CHAODA
• Origin：Shandong, China
• HS Code：8465990000
• Production Capacity：100 Sets ,Month

Basic Info.

Model NO. JCW1325R-4H Customized Customized Condition New Color Green and White Name 4 Axis 4 Head Rotary 3D CNC Wood Carving Machine, Structure Heavy Duty Steel Working Size 250mm Diameter; 1300mm Length Spindle 2.2kw Water Cooling Drive Stepper Motor and Driver Inverter Fuling Controller DSP Xyz Linear Square Guide Rail Xy Rack and Pinion Z Ball Sceww Working Voltage 3 Phase AC380V 50Hz Option 1 6/8/10/14 Heads Option 2 Flat Table Option 3 3D Scanner Option 4 Air Cooling Spindle Transport Package Standard Wooden Case Specification 4 Axis 4 Head Trademark CHAODA Origin Shandong, China HS Code 8465990000 Production Capacity 100 Sets /Month

Product Description

High Quality 4 Axis 4 Head Rotary 3D CNC Wood Carving Machine, CNC Router

• This item is very suitable for furniture bulk production, multi heads can work at the same time, also can work alone, many times increasing efficiency.
• Adopt 4 axis DSP control system, very stable and easy to use.
• Well compatibility in software: all kind of 3D carving softwares.
• We can make Multi heads machine with any working size according to customers' specific requirements.
• Except furniture legs, it also can process 3d sculptures and complex artworks, can easily engrave 360 degree Human body, Buddhist statue, sculptures and other art works.

Model No.	JCW1325R-4H
Machine structure	Heavy duty steel structure
Table	Removable; T-slot with clamps (option)
Rotary working size	250mm diameter,1300mm length * 4 PCS
Spindle power	2.2kw /3kw water cooled spindle
Max moving speed	20m/min
Max working speed	15m/min
Control system	4 axis DSP
Motor	Stepper motor and driver
Inverter	Fuling
Max Burden weight	1000kg
Option	4 / 8 / 10 / 14 heads
Voltage	AC380V,3 phase,50Hz

This machine is very suitable for furniture bulk production, like sofa legs, table legs, chair legs, bed legs, bed
head, stair handrails, prop guns, wooden column cylinders... it also can make 3d small statues, figures,
sculptures,360 degree human body, Buddhist statues… etc.



1. Sample testing before shipment
2. Provide 2 days free training for each machine
3. 12 months warranty for each machine
4. Friendly English version manual and operation videos for studying
5. Free technical support by phone,email,chatting or remote
6. Engineers available to service machinery overseas
