• Model NO.：DW1325
• Customized：Customized
• Condition：New
• Color：Customized
• Max Feeding：4m-5.5m,Min
• Work-Holding：2m-3m,Min
• Resolution：0.005mm
• Interface：USB
• Command：G Code*.U00*.Mmg*.Plt
• Drive Motor：Stepper
• Spindle Power：5.5 Kw
• OEM：Accepted
• Customize：Accepted
• Control System：DSP ,PCI Card,Mach3
• Transport Package：Plywood Box, Free From Fumigation
• Specification：CE, SGS
• Trademark：DWIN
• Origin：Jinan, Shandong, China
• HS Code：846599
• Production Capacity：50 Sets Per Month

Model
DW1325
Working Area
1300×2500×200mm
Spindle Motor
5.5kw water cooling spindle
Working Mode
Leadshine stepper motor and drivers
Control System
Weihong NK105
Drive Mechanism
Rack and pinion on x,y axis
Table Surface
T-slot table
Frame
wholly steel structure
Motion Positioning Accuracy
± 0.03/300mm
Repositioning Accuracy
± 0.05mm
Max Motion Speed
50,000mm/min
Max Engraving Speed
30,000mm/min
Rotating Speed of Spindle
2,4000rpm
Z-axis setting
Auto Z origin tool sensor
Dictate Format
G code, *.u00, *.mmg, *.plt
Operating Voltage
3phase 380v
Software
Ucancam Type3 Router8 original with Dongle or Wentai (ArtCUT),
 ArtCAM software
Packing Size
3100*2050*1500mm
Lubrication System
Oil lubrication system
Gross Weight
1200kg
Noise Level
Racing
LAeep dB(A)72±1
Engraving
LAeep dB(A)80±2
Engraving Peak
LAeep dB(C)95
Optional Parts
Dust Collecting System
Mist Sprayer and flume
Rotary device with Dia80mm/100mm/200mm
Nc-studio/Syntec


After-sale Service:
1.18 months quality guaranty, the machine with main parts(excluding the consumables)
   shall be changed free of charge if there is any problem during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. We will provide the consumable parts at an agency price when you need replacement.
5. 24 hours on line service each day, free technical support.
6. Machine has been adjusted before delivery.
7. Our staff can be sent to your company to install or adjust if necessary


Before buy pleas let us know:
 If you not sure which model is suitable for your work please provide the following information:
1.What is main products you process?
2.The main material and max length and width.
3.Mainly do engrave or cut, how about the thickness
4.Your destination port, to check shipping price
