A4 Series Sign CNC Machine Atc CNC Router for Woodworking
Jinan Sign CNC Equipment Co., Ltd.- After-sales Service：Suport
- Warranty：Suport
- Condition：New
- Certification：CE
- CNC or Not：CNC
- Voltage：220V,50Hz, or 380V
Base Info
- Model NO.：A4-1325-L8
- Woorking Area：1300*2500*300mm
- Spindle Power：9.0kw
- Guide Rails：Hiwin Square Guide Rails
- Command Code：G Code
- Control System：Syntec FC60ca
- Model of Driver：Leadshine
- Z- Axis Height：300mm
- Oil Lubrication System：Manual
- Spindle：Air Cooling
- Motor：Servo
- Transport Package：Standard Export Wooden Box
- Specification：17 CBM
- Trademark：SIGN CNC
- Origin：China
- HS Code：846599
- Production Capacity：300 Set,Month
Description
One year Contain:
Option:
Samples
Payment methods:
Package:
All the machine parts have been packaging, and whole of the machine with waterproofing membrane. And then have been package use standard wood case (The fumigation-free ), on the case top and bottom have steel tube for support. let it more strong to avoid damage during the transport and for long distance transportation.
FAQ
1. Q: How do you send your machine?
A: We can send our machines by sea, land and rail way, or we can send the machine to your doors.
| NO. | Name | Features and use | Quantity |
| 1 | Frame of machine bed | Large steel tube welding | 1 set |
| 2 | Gantry | Heavy duty | 1 set |
| 3 | Spindle | 9kw air cooling spindle | 1 pc |
| 4 | Inverter | 11kw Fuling | 1 pc |
| 5 | Motor | Leadshine 750W servo motor | 4 sets |
| 6 | Driver | Leadshine 750W servo driver | 4 sets |
| 7 | Syntec control card | FC60CA | 1 set |
| 8 | Hand wheel | Operate for simple work | 1 pc |
| 9 | Control cabinet | Computer cabinet and electrical component installation | 1 pc |
| 10 | Guide rails | Hiwin 25 square guide rails | 1 set |
| 11 | Rack gear | Helical rack and gear | 1 set |
| 12 | Working table | Vacuum table with T-slot | 1 set |
| 13 | Vacuum pump | Suction the air between the material and the table to be a vacuum to fix the material. | 1 pc |
| 14 | Positioning pneumatic cylinder | To fix the plate faster and more accurately, improving work efficiency | 1 pc |
| 15 | Auto oil lubrication system | Lubrication the rails and rack gear | 1 pc |
| 16 | Dust collector | 3kw double bags | 1 pc |
| 17 | Tool sensor | Adjust the distance from the tool to the materials | 1 pc |
| 18 | Tool Magazine | Place of put the cutter with 8 position | 1 set |
| 19 | Collets | Hold the bit on the spindle | 8 pcs |
| 20 | Materials holder | Fixing material when engraving | 8 set |
| 21 | Cutter | Used for engraving and cutting | 2 box |
| 22 | Connecting cables | Data Cable, Power Cable, etc. | 1 set |
| 23 | Wrench | Used for change the cutter or routine maintenance | 2 pcs |
| 24 | L-type screwdriver | Used for L-type screwdriver | 1 set |
| 25 | Tool box | Loading tools and some gadgets | 1 pc |
Option:
Samples
Payment methods: | MOQ | 1 set |
| Port of loading | Qingdao, China. Other cities are ok |
| Time of delivery | 15 working days after receiving payment |
| Payment methods | T/T in advance, 50% deposit, the balance should be paid before shipping |
Package:
All the machine parts have been packaging, and whole of the machine with waterproofing membrane. And then have been package use standard wood case (The fumigation-free ), on the case top and bottom have steel tube for support. let it more strong to avoid damage during the transport and for long distance transportation.
FAQ1. Q: How do you send your machine?
A: We can send our machines by sea, land and rail way, or we can send the machine to your doors.
