Cast Iron 6090 Wood CNC Router 4 Axis Aluminum Cutting Milling Machine with 1.5kw Water Cooling Spindle

Shandong Lintianzhiyuan CNC Equipment Co., Ltd.
  • After-sales Service：Free Parts
  • Warranty：2 Years
  • Condition：New
  • Certification：CE
  • CNC or Not：CNC
  • Voltage：220V

Base Info

  • Model NO.：LT-6090
  • Working Area：600X900mm
  • Machine Structure：Cast Iron
  • Table Type：Cast Iron
  • Gantry：Cast Iron
  • Moving：Table Moving
  • Spindle：1.5kw Water Cooling Spindle
  • Collet：Er16
  • Spindle Speed：0-24000 Rpm,Min
  • Transmission：X,Y,Z Axis by Tbi Ball Screw
  • Driving：Leadshine Stepper Motor and Driver
  • Control System：Nc Studio,Mach3 with USB
  • Software：Artcam
  • G Code：.Nc .Mmg
  • Transport Package：Plywood Case
  • Specification：1600x1300x1730mm
  • Trademark：LINTCNC
  • Origin：China
  • HS Code：8465990000
  • Production Capacity：300 Pieces,Year

Description

Overview Product Description

Product ParametersWorking area600x900mmMax. feeding height of Z axis200mmMachine structureCast ironMachine tableCast ironSpindle power1.5kw/2.2kw/3.0kw water cooling spindleSpindle speed0-24000 rpm/minTransmissionTaiwan TBI ball screwGuide railHiwin square guide railDrivingLeadshine stepper motor and driverWorking Accuracy0.03/300mmControl systemNC studio/Mach3 with USB/DSPSoftwareArtCAMVoltageAC 220V, 50/60HzDetailed PhotosFeedback from other customersHow to contact us?

Cast Iron 6090 Wood CNC Router 4 Axis Aluminum Cutting Milling Machine with 1.5kw Water Cooling Spindle
