New 1300mm 2600mm Log Debarker for Plywood Prodution
Linyi Gaotong Import & Export Co., Ltd.- After-sales Service:Online Technical Support
- Warranty:2 Years
- Type:Log Debarker
- Automatic:Automatic
- Certification:CE, ISO
- Condition:New
Base Info
- Model NO.:GTWM001
- Peeling Rate:99%
- Wood Loss Rate:8%
- Wood Lenght Range:1300,2600mm
- Power:35.5kw
- Weight:8000kg
- Dimension:4800*2200*1500mm
- Voltage:380,415,440
- After Sale Service:Online Technical Support and Training
- Power of Double Roller:7.5kw*2
- Power of Oil Pump:5.5kw
- Max Opening:550mm
- Length of Roller:7.5kw*2
- Feature:Heavy Duty
- Transport Package:in Nude
- Specification:2.6m
- Trademark:GTCO
- Origin:China
- HS Code:8439
- Production Capacity:2,Day
Description
LOG DEBARKER Model LDP2700-550 LD1500mm-550 Max Length of log 2600mm 1300mm Max Diameter of log 550mm 600mm Min Diameter of log 80mm 80mm Speed 45m/min 45m/min Blade size 2700*180*16mm 1500*160*13mm Total Power
(24KW ) Double Roller Motor Φ150mm ,11KW
Single Roller Motor Φ150mm , 7.5KW
Hydraulic Motor 5.5KW Double RollerΦ200mm/ Motor ,11KW
Single RollerΦ180mm/ Motor ,7.5KW
Hydraulic Motor , 5.5KW Overall size 5200*2200*1100mm 3500*2250*1450mm Weight About 5000KGS About 3500KG
(24KW )
Single Roller Motor Φ150mm , 7.5KW
Hydraulic Motor 5.5KW
Single RollerΦ180mm/ Motor ,7.5KW
Hydraulic Motor , 5.5KW
