Hot Press Plywood Machine
Linyi Zhongfu Wood Machinery Co., Ltd.- Type：Hot Press Machine
- Automatic：Automatic
- Certification：CE, ISO
- Warranty of Core Components：1 Years
- Marketing Type：New Product 2021
- Max.Pressure(T)：500
Base Info
- Model NO.：Hot press
- Video Outgoing-Inspection：Provided
- Working Table Size(mm)：2700*1370
- Condition：New
- Core Components：PLC, Engine, Bearing, Gearbox, Motor
- Pressure：600 Tons , Customzied
- Weight (Kg)：30000 Kg
- After-Sales Service Provided：Field Installation, Commissioning and Training
- After Warranty Service：Online Support, Spare Parts, Field Maintainance
- Key Selling Points：Automatic
- Applicable Industries：Manufacturing Plant, Plywood
- Steel Material：Q235 Q345
- Finished Products：4*8 Feet Plywood
- Transport Package：Nude Loading in The Container
- Specification：500Tons 1600mm Opening
- Trademark：Zhongfu
- Origin：Shandong, China
- HS Code：8465990000
- Production Capacity：10 Set,Sets Per Month Hydraulic Cold Press
Description
Pressure
500 ton
Direction of feeding plate
horizontal
Layers
15
Hot platen distance
70mm
Hot plate qty
16 pcs
Heating platen size
2700*1370*42mm
Qty of Cylinder
2
Diameter of cylinder
360mm
Stoke of cylinder
1050mm
Pressure of hydraulic system
≤25Mpa
Average pressure of hot platen
13.75kg/cm²
Closing time
15s
Control system
PLC
Upper ,bottom crossbeam
900mm
Thickness of main frame steel
35mm Q245
Steel material
Q235
