Woodworking Press Machine Cold Press for Plywood
Linyi Zhongfu Wood Machinery Co., Ltd.- After-sales Service：Field Installation, Commissioning and Training
- Warranty：1 Year
- Type：Cold Press Machine
- Automatic：Automatic
- Certification：CE, ISO
- Warranty of Core Components：1 Years
Base Info
- Model NO.：Woodworking press machine cold press for plywood
- Marketing Type：New Product 2021
- Max.Pressure(T)：500
- Video Outgoing-Inspection：Provided
- Working Table Size(mm)：2700*1370
- Condition：New
- Core Components：PLC, Engine, Bearing, Gearbox, Motor
- Pressure：500 Tons , Customzied
- Weight (Kg)：15000 Kg
- After-Sales Service Provided：Field Installation, Commissioning and Training
- After Warranty Service：Online Support, Spare Parts, Field Maintainance
- Key Selling Points：Competitive Price
- Applicable Industries：Manufacturing Plant, Plywood
- Board Feeding Direction：Transverse
- Opening：1600mm
- Transport Package：Nude Loading in The Container
- Specification：500Tons 1600mm Opening
- Trademark：Zhongfu
- Origin：Shandong, China
- HS Code：8465990000
- Production Capacity：10 Set,Sets Per Month Hydraulic Cold Press
Description
Model
500Tons 1600mm Opening
Cylinder position
Down stroke
Board feeding direction
Transverse
Opening
1600mm
Working size
2700*1370mm
Cylinder
2*360mm*900mm, 2*100mm*900mm(lifting cylinder)
Stroke
800mm
Compression resistance
25 Mpa
Power
11KW
Overall dimension
3550mm*1370mm*4600mm
Weight
About 15Tons
Working methods
Full automatic
Loading method
Automatic roller conveyor
Composite frame
Assembled
Upper and bottom beam
900mm
Thickness of the frame
35mm
Middle beam
400mm
