• Model NO.：S300
• Movement Method：Contour Control
• Control Method：Closed-Loop Control
• Numerical Control：CNC,Mnc
• Processing Precision：0.01~0.02(mm)
• Performance Classification：MID-Range CNC Machine Tools
• Configuration：9kw Air Cooling Spindle + Circular Tool Change
• Other：Also Include Drilling Bank (5+4)
• Transport Package：Wrapped in Layers of Wrapping Film and Ponchos
• Specification：1300*2500*300mm
• Trademark：Mars
• Origin：China
• HS Code：8465990000
• Production Capacity：3000 Sets,Year

BasicX/Y/Z Axis Working Area1230*2450*200mmMachine Size3700*3100*1900mmWorking TableWhole line frame structure, firm and not deformation, vacuum adsorption table plus automatic positioningTable StructureDouble vacuum chamber absorption tableBody StructureHeavy-duty thicken steel structure w/ temperingMainControl SystemTaiwan Syntec control systemDrive SystemJapan Yaskawa servo motorSpindle Motor PowerHSD 9KW air cooling spindle; 0 ~ 24000 rpm/min






OthersTool MagazineCarousel, 8pcsDrilling HeadItaly HSD 5+4 gang drillLubrication SystemAutomaticTransmissionXY axis rack and pinion PMI, Z axis ball screw TBIGuide RailTaiwan PMI/Hiwin 25mm rectangular linear railInverterZoncn/Delta/Fuling brandPositioning cylinder6pcsTool sensorMARSLimit switchJapan OmronVacuum Pump1*5.5KW double leaf vacuum pumpCableMARS cable, anti-static, anti-interference, bending resistanceBeamReinforced steel beamMax Travelling Speed50m/minMax Processing Speed30m/minWorking Accuracy±0.02mmRe-positioning Accuracy±0.05mmDictate FormatG-Code / HPGLWorking VoltageAC380V/ 3PH/ 50HZSupport SoftwareProfessional cutting optimization software(JiFusen/Yunxi/Tomder/Haisense)Net Weight3000KG
Accessories:


Performance Features:

1	Equipped with all the leading international brand components, Taiwan Syntec control system, Japan Yaskawa servo motor and driver
2	Carousel type tool magazines support automatic tool changer, improve processing efficiency
3	HSD 9KW high-power air-cooling spindle can withstand high-speed, heavy loading, low noise characteristics
4	Machine body structure is made of welded thick-walled square steel tube, with five-sided tempering, to ensure the body never deformation
5	Vacuum table, high adsorption capacity, able to adsorb materials of different sizes
6	Taiwan-made guide rail and ball screw, high precision, long service life, good stability
7	Taiwan Syntec control system, easy to operation,fully support automatic production. It can automatically accomplish multi-layer 3D job, cutting, engraving, milling. Offline operation can be realized.
8	Taiwan planetary reducer, with small volume, large torque, high transmission efficiency, wide range of deceleration
9	Intelligent protection work table can prevent table damages caused by misuse or software errors. Intelligent processing cross-border protection can prevent mechanical collisions while design layout exceeds processing area

Samples:
