• Model NO.：1325W-4
• Driver：Delta (Optional Yaskawa)
• Motor：750W
• Spindle：6kw & 4.5kw, Air Cooling
• Control System：Nc Studio 3L
• Transport Package：Plywood Case
• Specification：DT1325W-4
• Trademark：DONGTONG
• Origin：Shandong China
• HS Code：84659900
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. 1325W-4 Driver Delta (Optional Yaskawa) Motor 750W Spindle 6kw & 4.5kw, Air Cooling Control System Nc Studio 3L Transport Package Plywood Case Specification DT1325W-4 Trademark DONGTONG Origin Shandong China HS Code 84659900 Production Capacity 100 Sets Per Month

Product Description

Multi Process engraving machine,
Multi Workstage CNC Router,
Multi Spindles CNC Router,
4 Workstage ATC CNC Router,
 from Professional cnc woodworking machine manufacturer.



1. DT 1325W-3 engraving machine is designed for board, furniture, handicraft, etc. Four Workstage ATC functions bring us high-efficiency and high quality.
2. Lathe bed adopts welded structure, high strength and no variant, ensure the machining accuracy.
3. For Y axis, double motor drive, power stable operation, high precision.
4. Genuine NC Studio 95A for control system.
5. Support breakpoint processing, easy to adjust.
6. All kinds of machine models can be customized according to the clients' requirements.

Modle: 1325W-4
Machine size: 3200x2200x2100mm
Packing size: 3300x2280x2500mm
Working area: 1300mm×2500mm
Total power: 25W
N.W.: 1600Kg

Transmission	XY:Rack;Z:Screw
Screw No.	PMI 2510
Guild rail	HIWIN 25
Driving mode	Servo
Driver	Delta
Motor	Delta
Motor power	750W
Working voltage	380V
Gantry	10MM welded structure
Operation system	Nc Studio 95A-3L
Spindle	HQD 4.5KW x2; 6KW x2, Air cooling
Lubrication	Auto
Limit switch	Omron
Dust collector	3kw, two bags
Table	Vacuum (4 area)
Reducer	Shimpo from Japan
Vacuum pump	380V/ 5.5KW Air pump



NO	Index	Index	Parameter
1	Traveling	X axis	1300mm
		Y axis	2500mm
		Z axis	180mm
2	Table size		1300x2500mm
3	Accuracy	Working accuracy	0.02mm
		Reposition accuracy	0.02mm
4	Transmission	X axis	Rack
		Y axis	Rack & Double moters
		Z axis	Screw
5	Speed	Max Rapid	25000mm/min
		Max working speed	15000mm/min
6	Spindle	Spindle power	6KWx2Pcs; 4.5KWx2pcs
	(Water-cooling)	Spindle speed	0-18000r/min
7	Drive mode		Servo
8	Working voltage		AC380/50HZ
9	Command language		G Code
10	Operation system		Nc Studio 95A-3L

If  you have specific requirement for it, customized is available.






Sincerely waiting for your any inquiry, and trust that we can provide you professional suggestions.



 Guarantee & After-sale service1.One year warranty under normal use and we supply lifelong maintenance.2.24 hours technical support by Phone, Email, Skype, Msn, or romote.3.Free training to make sure you master the operation of the cnc router.OEM Service Available1.Usually, we will manufacturer the machine as our regular design.2.X Y Z Working Area could be custmer-oriented designing.3.Special configuration could be customer-oriented designing.
