CE Approved Metal Mild Steel Plate CNC Router Cutting/Carving Machine
Perfect Laser (Wuhan) Co., Ltd.- Warranty：1year Warranty
- Type：Engraving Router
- Spindle Layout：Vertical
- Spindle Number：Single-Spindle
- Feed Mode：Manual
- Controlling Mode：CNC
Base Info
- Model NO.：PEM-6090
- Certification：CE, ISO, TUV
- Customized：Customized
- Condition：New
- Color：Blue
- After-sales Service：Online Support
- Spindle Power：1.5kw, 2.2kw, 3kw, 4.5kw
- Working Area：900*600, 1200*1200, 1200*1500, 1200*1800, 1300*250
- Table Material：Aluminium Alloy
- Max Engraving Speed：4, 000-7, 000mm,Min
- Spindle Cooling：6000 - 24, 000rpm
- Interface：PCI Port or USB Port
- Operational Software：Original Type3 Software, Artcam Software or Wentai
- Software Compatibility：Support CAD,Cam Software, Plt Format, Corel Draw
- Application：Cutting and Engraving Nonmetal and Metal Material
- Command Language System：English
- Transport Package：Export Sea-Worthy Packing or Air-Worthy Packing
- Specification：ISO 9001 & CE
- Trademark：Perfect Laser
- Origin：China
- HS Code：84609090
- Production Capacity：3000 Sets,Year
Description
Application:
Advertising CNC Router is widely used in the field of Advertising board, Label design, Acrylic cutting, model of the multi material decoration products.
Which is also widely applied in engraving and cutting on all kinds of metal and nonmetal materials, such as wood engraving, wood cutting , MDF Engraving, MDF Cutting, PVC plastic Engraving, PVC plastic Cutting, plexiglass engraving, plexiglass cutting, acrylic engraving, acrylic cutting ,organic glass engraving, organic glass, etc.
Features:
1) X, Y, Z axis use imported ball bearing guide screws. It's precise and fast. Even the letters of 1mm can be clearly discernible. The small-power machine uses large-power main axis, it's an ideal product for manufacturing labels, construction models and moulds in batches.
2) High speed calculation It uses DSP64 contouring control system and FPGA technology which can continually and smoothly run the three axes with high speed. It has the ability of calculation of 5000 vector/s.
3) Steble data transmission. Adopt ISA/IP DNC/IP straight technology, it associate the machine without interruption, enable no limitation of the amount of the document.
4) Double-nut guide screw .It uses Germany-imported high-precision ball bearing guide screw which can eliminate cracks automatically. Coordinated with the imported shaft coupling, it can realize precise control. It uses straight line guide rail (cylinder or square), which can ensure the working life.
5) Large internal memory capacity of 32M is able to store 30 processing files simultaneously and open and process any of them.
6) Connection with the computer via USB interface enables data to be transmitted in a second, supports hot plug and play, no driver installation required(WindowXP)
