• Model NO.：1325
• Customized：Customized
• Condition：New
• Color：Customized
• Model：1325
• Spindle：Plasma Torch
• Guide Rails：Hiwin Liner Square Guide Rails
• Ball Screw：Tbi Ball Screw
• Plasma Power：Lgk Plasma Power
• Control System：Start Control System
• Motor：Stepper Motor
• Driving Way：Stepper Motor
• Transmission in X,Y：Helical Rack
• Table Surface：Knife Table Surface
• Transport Package：Exporting Plywood Package
• Specification：1300*2500*200mm
• Trademark：zhongke
• Origin：Jinan Shandong China
• HS Code：8456401000
• Production Capacity：100set ,Month

ModelZK1325X,Y,Z axis working area1300*2500*200mmWhole structureWelded Steel gantry structureTable surfaceKnife table surfaceX,Y,Z structureTaiwan PMI/HIWIN Square linear guide railX,Y structureRack and pinion transmission, high speed and more stable;
Y -double motor driveZ structureImported ball screw, high precisionMax. idling speed50m/minMax. working speed25m/minRepositioning Accuracy±0.05mmX Y Z working Accuracy< 0.02mmSpindlePlasma torchSpindle rotating speed600-18000rpm/minDiameter of toolsΦ3.175 -Φ20Collect sizeER 25Operation languageG code (plt, mmg, uoo, bmp)Driving systemStepper motorOperating systemSTART control system(can be optional NK105)Working voltage220V/380V/3PHSoftwareUcancamV8 / Type3 / Artcam software (option)After sale service:
1 we offer 1 year warranty
2 we offer 24 hourses technical support online
3 Druring the warranty, if there is part broken, we will offer you the same for free.
Factory photo
