• Model NO.：CA-3636,3040,1212,1224,6012,6090
• Certification：ISO, CE
• CNC or Not：CNC
• Voltage：220V
• X,Y,Z Working Area：360mmx360mm
• Table Size：640mmx680mm
• X,Y,Z Traveling Positioning Accuracy：+-0.03,300mm
• X,Y,Z Repositioning Positioning Accuracy：+-0.05mm
• Lathe Structure：Cast Steel
• X, Y Structure：Shaft Linear Bearings and Ball Screw
• Z Structure：Taiwan Tbi Ball Screw
• Max. Consume Power：3.0kw
• Max. Speed：0-8000mm,Min
• Max. Working Speed：0-6000mm,Min
• Spindle Power Motor：2.2kw Water-Coolant Spindle
• Spindle Speed：0-24000rpm
• Drive Mode：Stepper Motor and Driver
• Operating System：4 Axis Mach3 System
• Command：G Code, *Uoo, *Mmg, *Plt
• Transport Package：Plywood
• Specification：3636
• Trademark：CAMEL CNC
• Origin：China
• Production Capacity：500 Sets,Month
• Package size per unit product：1180.00cm * 960.00cm * 1420.00cm
• Gross weight per unit product：200.000kg
