• Model NO.：1325
• Customized：Customized
• Condition：New
• Color：Customized
• Spindle：Water Cooling Spindle
• Oiling Mode：Pressing Lubricating
• Control System：Ncstudio Control System
• Square Rail：Taiwan Hiwin Square Rail
• Motor：Stepper Motor
• Driver：Stepper Driver
• Ball Screw：Taiwan Tbi Ball Screw
• Inverter：Sunfar Inverter
• Table：Alumnium Table
• Name：3D CNC Router for Wood Machine
• Transport Package：Exporting Plywood Package
• Specification：1300*2500*200mm
• Trademark：ZK
• Origin：China
• HS Code：8465990000
• Production Capacity：100 Per,Months

Basic Info.

Model NO. 1325 Customized Customized Condition New Color Customized Spindle Water Cooling Spindle Oiling Mode Pressing Lubricating Control System Ncstudio Control System Square Rail Taiwan Hiwin Square Rail Motor Stepper Motor Driver Stepper Driver Ball Screw Taiwan Tbi Ball Screw Inverter Sunfar Inverter Table Alumnium Table Name 3D CNC Router for Wood Machine Transport Package Exporting Plywood Package Specification 1300*2500*200mm Trademark ZK Origin China HS Code 8465990000 Production Capacity 100 Per/Months

Product Description

Feature:

1 Welded steel bed structure , when working its more stable.

2  Alumiun T-slot table, fixing the materiales by clamps

3 Sunfar brand inverter

4 Ncstudio control system

5 Water cooling spindel .

6 TaiWan high precision HIWIN square liner guide rail, improving working accuracy.

7 Stepper motor working mode

8 Transmission by helick rack

9 TaiWan TBI Ball Screw

10 Servo motor and SYNTEC control system is optional





Specification:



Model	ZK 1325 CNC router
X,Y,Z Working Area	1300*2500*200mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
X,Y,Z repositioning Positioning Accuracy	±0.02mm
Lathe Structure	Thick wall square tubes welding bed
X Structure	Taiwan HIWIN square guide rails
Y Structure	Taiwan HIWIN square guide rails
Z Structure	Taiwan TBI ball screw
Max.Speed	0-30000mm/min
Max.Working Speed	0-25000mm/min
Spindle	water cooling spindle
Spindle Speed	6000-24000RPM
Working Mode	Stepper motor
Working Voltage	380V/3ph    50HZ/60Hz for standard machine, if optional vacuum system  or servo system, it need 380V 3 phase
Command Code	G code(*uoo,*nc,*mmg, *plt)
Operating System	Ncstudio control system or DSP control system( also can choose  LNC or SYNTECH control system, it depends on your requirement)
Interface	USB
X,Y Working Delicacy	<0.01mm
Software	Type3 software or Wentai software
Running circumstance	Temperature: 0°C~45°C
Waranty	One year
Delivery time	2 weeks

Sample photo:





Applied Area: wood materials,wood doors,relief engraving of the furniture, panel furniture,decoration materials.



FAQ:
Q1:  How can I get suitable machine?
     A:First: Please tell us what's your max working area.
     Second: Please tell us what material will be engraved or cutted?
     Third: Please tell us what kind of product do you want to get.
     Those three answers will help us choice suitable CNC Router for you.
Q2: What is your delivery time?
      A:It depends on what kind CNC Router you order? But for common CNC Router, our production time is 15 working days.
Q3: Do you have operation manual for machine?
     A:Surely we have, there have how to intall and operation machine, how to maintain machine and what place need to be notice during using our machine. We will sent CNC Router manual to you with our CNC Router machine.
Q4: This is the first time I use this kind of machine, is it easy to operate?
    A:Yes, We will send you manual and guide video in English, it can teach you how to operate the machine. If you stilldon't know how to operate it, we can help you by phone or WhatsApp,Skype.
Q5:How should I pay for my order ? what is the procession of this purchase?
    A:We accept TT by bank. you can do 30% prepayment at first, then we will start to make machine. when the machine is ready , we will take pictures to you, after we got you payment.We will send the machine to you.
